Ubiquiti Networks UISP Switch Plus Overview
With its versatile design, the UISP Switch Plus 4-Port 2.5G PoE Compliant Managed Switch from Ubiquiti Networks supports both indoor and outdoor installations that require power and high bandwidth. Mountable onto a desktop, wall, or 1 RU rack, this managed switch offers four 2.5G Ethernet ports, each of which provides up to 40W of power to compatible devices with a total budget of 160W.
Additionally, four SFP+ ports are available for up to 10 Gb/s fiber links. Other features include port isolation, speed limiting, and DHCP snooping functionality. You can manage this switch through a local web interface and via the UISP application.
Items Included
- Ubiquiti Networks UISP Switch Plus 4-Port 2.5G PoE Compliant Indoor/Outdoor Managed Switch
- Power Adapter & Cables
- Wall & Rack Mounting Kits
- SFP Port Plug
- Prying Tool
- Limited 1-Year Manufacturer Warranty
Additional Resources
No additional resources available
Ubiquiti Networks UISP Switch Plus Specs
| Inputs/Outputs |
4x RJ45 2.5 GbE PoE (Unspecified) 4x SFP+ 10 GbE |
| PoE Power Budget |
160 W |
| Inputs/Outputs |
4x RJ45 2.5 GbE PoE (Unspecified) 4x SFP+ 10 GbE |
| Stackable |
No |
| Forwarding Rate |
74.4 Mpps |
| Switching Bandwidth |
100 Gb/s 50 Gb/s (Non-Blocking) |
| Flash Memory |
256 MB |
| CPU |
Dual-Core: Up to 1.4 GHz Cortex |
| Memory |
1 GB DDR4 |
| Power Draw |
25.00 W (Active) |
| DC Input Power |
27 VDC at 7.04 A |
| AC Input Power |
No |
| PoE Power Budget |
160 W |
| Power Supply Type |
External |
| Operating Temperature |
14 to 122°F / -10 to 50°C |
| Operating Humidity |
5 to 95% |
| Certifications |
CE, FCC, IC |
| Cooling System |
Passive |
| Material of Construction |
Steel |
| Indicator Lights |
Link/Activity, Link/Activity/Speed, PoE, Status |
| Dimensions |
8.3 x 6.7 x 1.7″ / 210.4 x 170.2 x 43.7 mm |
| Package Weight |
8.74 lb |
| Box Dimensions (LxWxH) |
10.9 x 10.6 x 5.8″ |
