Turtle SanDisk Professional PRO-BLADE Station Waterproof Case(Turtle Sandisk Professional Pro Blade Station Waterproof Case)

Certifications

Waterproof IPX7
Dustproof IP6X
Impact ATA 300
Drop Test ASTM D-4169 CC-18
Vibration STM D-4169
Rainfall ASTM D-4169 DCc-18
Immersion MIL-STD-810F

ATA Specification 300 Category 1

Airline transport container suitable for a minimum of 100 airline trips

Impact Resistance Test�samples were exposed to impact using a bar weighing 13.2 lb with a hemispherical end of 1.3 inches. Bar was dropped with its longitudinal axis vertical on to each sample’s weakest point from a height of 1.6 feet. Samples were conditioned to a temperature of -4°F before impact exposure.

ASTM D-4169 DC-18

Level 1 Schedule A Handling (Manual)

Drop tests�a series of drops on each edge, corner, and face of the case from a height of no less than 19 inches and with loads of 15�70 lb determined by case size. Samples were conditioned at lab ambient conditions and then temperatures of -4°F and 140°F for a minimum of 3 hours at each condition.

ASTM D-4169 DC-18

Level 1, Schedule F loose load vibration

Vibration�the cases are tested using test method D-999 to determine the ability to withstand the repetitive shocks occurred during transportation of loose loads.

ASTM D-4169 DC-18

Level 1, Schedule H Environmental Hazard Rainfall

Simulated rainfall for 2 hours at a rate of 4 inches per hour. Samples were conditioned to -4°F and 140°F.

MIL-STD-810F

Method 512.4

Immersion�the case is submerged in a basin of water to a depth of 3.28 ft to the top most part of the case for 30 minutes. The case is heated to 10°F higher than the temperature of the water.
