Tripp Lite Eaton 9PX6K UPS(Tripp Lite Eaton 9px6k Ups)
Original price was: $309.00.$99.99Current price is: $99.99.
- Elevate Your Shopping Experience
- Product guarantee 100% satisfaction
- The quality solution for all your needs.
- Streamlined service, designed for your convenience.
Tripp Lite 9PX6K Overview
The Eaton 9PX6K UPS from Tripp Lite is a reliable, versatile, and efficient backup power supply for IT equipment, including Cisco switches and servers. It can provide three minutes of use when running a full load and up to 8.5 minutes when running a half load.
The 9PX6K UPS features an output of 5400W / 6000 VA, a NEMA L6-30P input connection with a 6′ cord, an input of 208V at 50/60 Hz ±10 Hz, two NEMA L6-20R outlets two NEMA L6-30R outlets, double conversion online topology, and a true sine waveform. Built with a three RU form factor, it includes a four-post rail kit, tower pedestals, an RS-232 serial cable, and a USB cable. Also included is a Gigabit Ethernet card and support is provided by a limited 3-year warranty.
Items Included
- Tripp Lite Eaton 9PX6K UPS
- Gigabit Network Card
- 4-Post Rail Kit
- Tower Pedestals
- RS-232 Serial Cable
- USB Cable
- Cable Gland for Hardwire Connection
- Phillips Head Screwdriver
- Limited 3-Year Manufacturer Warranty
Additional Resources
User Manual
11.9 MB
Tripp Lite 9PX6K Specs
| Total Outlets |
2x NEMA L6-20R 2x NEMA L6-30R |
| Plug Type |
NEMA L6-30P |
| Surge Protection |
Yes |
| Maximum Wattage |
5400 W |
| Full-Load Runtime |
3 Minutes |
| Total Outlets |
2x NEMA L6-20R 2x NEMA L6-30R |
| Protected Outlets |
2x NEMA L6-20R (Battery and Surge) 2x NEMA L6-30R (Battery and Surge) |
| Plug Type |
NEMA L6-30P |
| USB Charging Ports |
No |
| SmartSlot Interface |
No |
| Coax Protection |
No |
| Data Line Protection |
No |
| Communications I/O |
Gigabit Ethernet via RJ45 Serial via USB-B Serial via DE-9/DB-9 |
| Emergency Power Off (EPO) Support |
Yes |
| Topology |
Double Conversion |
| Transfer Time |
0 to 10 ms |
| Surge Protection |
Yes |
| Maximum Wattage |
5400 W |
| Nominal Input Voltage |
208 VAC |
| Input Voltage Range |
200 to 240 VAC |
| Input Voltage Adjustable Range |
176 to 276 VAC |
| Input Frequency |
50/60 Hz ± 10 Hz (Auto Sensing) |
| Nominal Output Voltage |
208 VAC |
| Output Voltage Range |
200 to 240 VAC |
| Output Frequency |
50/60 Hz |
| Voltage Distortion |
<5% |
| Load Capacity |
6000 VA |
| Circuit Breaker Rating |
20 A |
| Thermal Dissipation |
1245 BTU/Hour |
| Maximum Efficiency |
98% |
| Crest Factor |
3:1 |
| Power Factor Correction |
0.9 |
| Waveform |
Sine Wave |
| Chemistry |
Lead-Acid |
| Full-Load Runtime |
3 Minutes |
| Half-Load Runtime |
8.5 Minutes |
| Number of Batteries |
1 |
| User Replaceable |
Yes |
| Hot-Swap Support |
Yes |
| Operating Conditions |
32 to 104°F / 0 to 40°C up to 95% Humidity |
| Storage Conditions |
5 to 140°F / -15 to 60°C |
| Storage Altitude |
32,808′ / 10,000 m |
| Noise Level |
45 dBA |
| Certifications |
CE, cULus, NOM, TAA |
| Cable Length |
6′ / 1.8 m |
| Rackmount Size |
3 RU |
| Dimensions (W x H x D) |
28.4 x 17.3 x 5.1″ / 722 x 440 x 130 mm |
| Weight |
108 lb / 49 kg |
