Synology RackStation RS2423RP+ 12-Bay NAS Enclosure(Synology Rackstation Rs2423rp 12 Bay Nas Enclosure)
Original price was: $392.00.$96.99Current price is: $96.99.
- Elevate Your Shopping Experience
- Product guarantee 100% satisfaction
- The quality solution for all your needs.
- Streamlined service, designed for your convenience.
Synology RS2423RP+ External HDD/SDD Overview
- 1Description
- 2Robust Storage Server for Office Applications
- 3Built-In Data and Uptime Protection Solutions
- 4Collaboration and Communication Hub for Teams
- 5Reliable and Secure Virtualization and Containerization
- 6Private Video Surveillance
The DiskStation RS2423RP+ 12-Bay NAS Enclosure from Synology is a versatile and cost-effective storage server for central data storage and sharing, endpoint and server backup, surveillance management, and other business applications. With sequential reads of over 3500 MB/s and sequential writes of over 1700 MB/s, as well as the option to boost I/O speeds through SSD caching, the RS2423RP+ provides flexible storage with strong built-in data protection capabilities. Powered by Synology’s DiskStation Manager (DSM), the RS2423RP+ can be expanded with 12 additional drive bays, or use the PCIe 3.0 x8/x4 slot to install a 1/10/25GbE networking card.
The RS2423RP+ is equipped with a 3.35 GHz AMD Ryzen V1780B Quad-Core processor and 8GB of DDR4 ECC memory that can be expanded up to 32GB. This NAS is equipped with 12 drive bays that natively support 3.5″ SATA hard drives, as well as 2.5″ SATA hard drives and SSDs for data storage.
The RS2423RP+ runs on the Synology DiskStation Manager (DSM) OS, which is a browser-based operating system that helps to simplify managing your Synology NAS. Also featured are two USB-A 3.2 Gen 1 ports for peripherals and accessories, plus a mini-SAS HD expansion port for an RX1223RP expansion unit. Network connectivity is achieved via the one 10 Gigabit Ethernet port or two Gigabit Ethernet ports. For those who require RAID support, the RS2423RP+ supports RAID 0, 1, 5, 6, and 10, as well Synology Hybrid and Basic, each of which offers performance, data redundancy, or a combination of both. For those who do not require a RAID, JBOD is also available, allowing each drive bay to be individually utilized.
The RS2423RP+ is engineered to be energy efficient. Not only does it offer three 60 x 60 x 38mm fans to help keep the system running cool, its noise-dampening design makes for quiet operation. The server supports numerous scheduled power on / off cycles and hard drive hibernation to further minimize power consumption and operation expenses.
The Synology DiskStation RS2423RP+ 12-Bay NAS Enclosure operates on 100-240 VAC at 50/60 Hz using dual redundant power supplies and includes an accessory pack and two AC power cords. Protection is provided by a limited 3-year warranty.
- Sequential read speeds of over 3500 MB/s and sequential write speeds of over 1700 MB/s support large data transfer volumes and enable fast file sharing, syncing, and backup for multiple users
- All-flash hybrid storage support means that users can add SATA SSDs as storage volumes or read/write caches to speed up HDD volumes or an add-in card
- Built-in 10GbE connectivity and two Gigabit ports can be supplemented with additional 1/10/25GbE ports, thanks to a PCIe 3.0 expansion slot
- A simple capacity expansion is available whenever needed with a Synology RX1223RP Expansion Unit
- Hot-swappable drive trays and online volume management allow for storage management without downtime, while hot-swappable dual power supplies keep services running in case of issues with one power source
- Synology High Availability provides fast failover between two identical Synology units to keep services online when disaster strikes
- Snapshot Replication provides schedulable, near-instantaneous data protection with version control, ensuring that all shared folders and LUNs on your Synology system remain safe and available
- Hyper Backup protects your Synology system by backing up shared folders and configurations to multiple destinations, including the secure C2 Storage public cloud, with efficiency delivered by built-in deduplication, integrity checks, compression, and versioning
- Synology Active Backup Suite lets you consolidate protection of Windows clients and servers, Linux endpoints, Synology systems, VMware, Hyper-V VMs, and SaaS applications, maximizing storage efficiency with data deduplication technology
- Synology Drive supports file sharing, remote data access, cross-device and cross-site synchronization, on-demand file restoration, and backup
- The Synology Office extension lets users collaborate on documents, spreadsheets, and presentation slides in real time, supported by convenient options such as file versioning for easy restoration and password protection
- Synology Chat brings teams together with one-on-one chats, group chats, and encrypted private channels over multiple platforms
- Synology MailPlus7 provides a secure, reliable, and private email server
- Synology Calendar helps teams keep track of priorities with convenient calendar sharing and scheduling
- Synology Hybrid Share combines reliable on-premises storage and efficient syncing of shared folders in the cloud to enable seamless cross-site synchronization and local file access at LAN speeds
- Synology Storage Console for VMware or Windows platforms lets you manage VM storage components directly from your hypervisor. VMware VAAI integration and Windows ODX help offload storage operations and speed up data transfers
- Host lightweight containers and VMs for testing, sandboxing, and emergency recovery purposes with Docker and Synology Virtual Machine Manager, a native hypervisor that supports Windows, Linux, and virtual versions of DSM
- 8300+ supported camera models
- ONVIF support for a broader selection of cameras
- Private, subscription-free storage of recordings
- Access through web browsers, desktop clients, and mobile apps
- Event-based rules to trigger specific actions
- Email, SMS, and push notification options
- Simultaneous recording to the cloud with C2 Surveillance for an extra layer of data protection and more convenient sharing
In the Box
- Synology RackStation RS2423RP+ 12-Bay NAS Enclosure
- Accessory Pack
- 2 x AC Power Cords
- Limited 3-Year Manufacturer Warranty
Spec Sheet
1.7 MB
- Description
- Robust Storage Server for Office Applications
- Built-In Data and Uptime Protection Solutions
- Collaboration and Communication Hub for Teams
- Reliable and Secure Virtualization and Containerization
- Private Video Surveillance
Synology RS2423RP+ External HDD/SDD Specs
| CPU |
3.35 to 3.6 GHz Quad-Core |
| Processor |
AMD Ryzen V1708B |
| Total Installed Memory |
8 GB ECC DDR4 |
| Maximum Memory Capacity |
32 GB |
| Number of Bays |
12 x 2.5″/3.5″ |
| Inputs/Outputs |
1 x RJ45 10GbE 2 x RJ45 Gigabit Ethernet 2 x USB-A 3.0 / 3.1/3.2 Gen 1 1 x Mini SAS (Unspecified) |
| Compatible Drive Interface |
SATA (Unspecified Version) |
| Media Card Slots |
No |
| Form Factor |
Rackmount (2 RU) |
| RAID |
RAID 0, 1, 10, 5, 6, JBOD, Synology Hybrid |
| Hot-Swap Support |
Yes |
| PCI Expansion |
1 x PCIe 3.0 x8 (x4 Electrical) |
| Wake on LAN |
Yes |
| Link Aggregation and Failover Support |
Yes |
| Supported Protocols |
AFP CalDAV FTP L2TP NFS OpenVPN PPTP SMB SNMP SSH Telnet WebDAV iSCSI |
| Max Concurrent Connections |
2000 |
| Max Folders |
512 |
| Max Groups |
256 |
| Max User Accounts |
2048 |
| Installed Operating System |
Synology DiskStation Manager |
| Supported File Systems |
Internal: BTRFS, EXT4 External: BTRFS, EXT3, EXT4, FAT32, HFS+, NTFS, exFAT |
| Mobile App Compatible |
Yes *As of February, 2023: Check with manufacturer for the most up-to-date compatibility |
| Supported Browsers |
Chrome, Edge, Firefox, Safari |
| Supported Languages |
Brazilian Portuguese Czech Danish Dutch English French German Hungarian Italian Japanese Korean Norwegian Polish Portuguese Russian Simplified Chinese Spanish Swedish Thai Traditional Chinese Turkish |
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Source |
Internal Power Supply |
| PSU Wattage |
2 |
| Operating Temperature |
32 to 95°F / 0 to 35°C |
| Operating Humidity |
8 to 80% |
| Operating Altitude |
0.0 to 16,404′ / 0 to 5000 m |
| Storage Temperature |
-5 to 140°F / -20 to 60°C |
| Storage Humidity |
5 to 95% |
| Status Monitoring |
LED Indicator |
| Cooling |
3 x 60 mm Fans |
| Dimensions |
22.8 x 19 x 3.5″ / 578 x 482 x 88 mm |
| Weight |
26.2 lb / 11.9 kg |
| Package Weight |
32.1 lb |
| Box Dimensions (LxWxH) |
28.2 x 22.9 x 10.4″ |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
