Stmicroelectronics NUCLEO-G431RB Development Board Nucleo-G431RB STMG431RBT6U MCU Arduino Nano V3(Stmicroelectronics Nucleo G431rb Development Board Nucleo G431rb Stmg431rbt6u Mcu Arduino Nano V3)

STM32 Nucleo-64 development board with STM32G0431RB MCU supports Arduino and ST morpho connectivity. STM32 Nucleo-64 board comes with the STM32 comprehensive free software libraries and examples available with the STM32Cube MCU package.

• STM32G431RBT6 microcontroller in LQFP64 package
• 1 user LED shared with Arduino, 1 user and 1 reset push-summarys
• 32.768 kHz crystal oscillator
• Arduinoâ�¢ Uno V3 expansion connectorST morpho extension pin headers for full access to STM32 I/Os
• Flexible power-supply options: ST-LINK, USB VBUS or external sources
• On-board ST-LINK debugger/programmer with USB re-enumeration capability
• STLINK-V3E on Micro-AB USB connector
• 24 MHz HSE and MIPI® debug connector

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Product details

Silicon Manufacturer	STMicroelectronics
No. of Bits	32bit
Silicon Family Name	STM32G4
Core Architecture	ARM
Core Sub-Architecture	Cortex-M4F
Silicon Core Number	STM32G431RBT6U
Kit Contents	Nucleo-64 Dev Board STM32G431RBT6U
Product Range	–

Other details

Brand	STMICROELECTRONICS
Part Number	NUCLEO-G431RB
Quantity	Each
Technical Data Sheet EN
Product Change Notice EN
