StarTech 40-Pin PATA To 2.5″ SATA HDD/SSD/ODD Converter(Startech 40 Pin Pata To 2 5 Sata Hdd Ssd Odd Converter)
Original price was: $38.14.$26.70Current price is: $26.70.
- Elevate Your Shopping Experience
- Product guarantee 100% satisfaction
- The quality solution for all your needs.
- Streamlined service, designed for your convenience.
- IDE/SATA Data Power Combo/SP4 Connectors
- 133MB/s Data Transfer Rate
- Supports 2.5″, 3.5″, & 5.25″ SATA Drives
- No Software Required
- Optical Disk Drive Support
- SATA Revision 1.0 Specification
The 40-Pin PATA to 2.5″ SATA HDD/SSD/ODD Converter from StarTech enables you to connect a SATA I/II/III drive to an available IDE/ATA 33/66/100/133 motherboard port. This converter is a cost-effective solution that allows you to add SATA drives and keep your existing motherboard. It bridges the gap between a 2.5″, 3.5″, and 5.25″ SATA drive and an older IDE motherboard port. The converter also features ODD (Optical Disk Drive) support, allowing you to a add Blu-ray, DVD, or CD-ROM drives to an older IDE motherboard.
- Connects a SATA device to an IDE/ATA motherboard or controller card
- Complete hardware solution, no software required
- Support for 48-bit Logical Block Addressing (LBA)
- Compliant with SATA revision 1.0 specification and compatible with Ultra ATA 133 specification
- Supports 2.5″, 3.5″, and 5.25″ SATA drives
- ODD (Optical Disk Drive) support, including Blu-ray, DVD, and CD-ROM drives
- An internal solution for connecting your SATA hard drive to a motherboard that supports an IDE interface
- Suitable for use with older motherboards that do not support SATA
| Connector 1 | IDE (40-pin EIDE/PATA) |
| Connector 2 | SATA data and power combo (7+15-pin) |
| Connector 3 | SP4 (4-pin small drive power) |
| System and Cable Requirements | An IDE controller and ATA cable
Sold separately |
| Data Transfer Rate | Maximum: 133 MB/s |
| Chipset ID | Marvell – 88SA8052 |
| Operating Temperature | 40 to 122°F (5 to 50°C) |
| Storage Temperature | -13 to +176°F (-25 to +80°C) |
| Relative Humidity | 15 to 90% |
| Compliances | CE, FCC, RoHS |
| Dimensions (L x W x H) | 3.0 x 0.8 x 0.9″ (76.2 x 20.3 x 22.9 mm) |
| Weight | 0.5 oz (14.2 g) |
| Packaging Info | |
|---|---|
| Package Weight | 0.2 lb |
| Box Dimensions (LxWxH) | 6.7 x 5.7 x 1.2″ |
- LP4 Molex to SP4 Power Cable
- Limited 2-Year Warranty
