Speco Technologies H16HRLN 16-Channel 5MP HD-TVI Hybrid DVR With 2TB HDD(Speco Technologies H16hrln 16 Channel 5mp Hd Tvi Hybrid Dvr With 2tb Hdd)
Original price was: $352.00.$98.99Current price is: $98.99.
- Elevate Your Shopping Experience
- Product guarantee 100% satisfaction
- The quality solution for all your needs.
- Streamlined service, designed for your convenience.
Speco Technologies H16HRLN Overview
Record from and manage up to 16 cameras with the H16HRLN 16-Channel 5MP HD-TVI Hybrid DVR with 2TB HDD from Speco Technologies at resolutions up to 5MP for 8 configurable hybrid channels and 8 IP channels. This recorder is equipped with two SATA ports that each support an HDD up to 16TB, for a maximum capacity of 32TB (2TB preinstalled). H.265 video compression keeps file sizes manageable while maintaining the best quality possible.
This recorder supports two-way audio. HDMI and VGA ports enable video output to an external monitor at up to 4K UHD resolution (HDMI output only).
In the Box
- Speco Technologies H16HRLN 16-Channel 5MP HD-TVI Hybrid DVR with 2TB HDD
- Remote Control
- Optical Mouse
- Rack Ears
- Power Adapter
- Limited 5-Year Manufacturer Warranty
User Manual
6.5 MB
Speco Technologies H16HRLN Specs
| Signal | HD-TVI, IP |
| Number of Channels | 16 |
| Playback Resolution | HDMI: 4K UHD VGA: 1080p CVBS, Spot: |
| Recording Resolution | 4K at 8 fps 4 MP, 5 MP at 12 fps 3 MP at 15 fps 1080p, 720p, WD1 at 30 fps |
| PTZ Support | Yes |
| Bit Rate | 32 Mb/s to 96 Mb/s |
| IP Camera Support | 8 |
| Dual Streaming | Yes |
| 2-Way Audio | Yes |
| A/V Inputs/Outputs | HD-TVI: 8 x BNC Input 8 x RCA Audio Input 1 x HDMI Output 1 x VGA Output CVBS: 1 x BNC Output (, Spot) 1 x RCA Audio Output |
| Communication Inputs/Outputs | 1 x RJ45 Gigabit Ethernet 2 x USB-A 2.0 |
| Audio Inputs/Outputs | 8 Inputs 1 Output |
| System Connection | 2 x SATA 1 x eSATA |
| Wi-Fi | None |
| Network Protocols | DDNS, DHCP, DNS, HTTP, HTTPS, NTP, PPPoE, RTSP, SMTP, TCP/IP, UPnP |
| Network Bandwidth | 96 Mb/s |
| Supported Video Codecs | H.265 |
| Backup Method | External HDD, USB Drive |
| Installed Drive | 2 TB Hard Drive |
| Max Capacity Supported | 16 TB (Each Drive) 32 TB (Total) |
| OS Compatibility | Android iOS *As of January, 2023: Check with manufacturer for the most up-to-date compatibility |
| Recording Modes | Analytics, Continuous, Motion, Sensor |
| Search Modes | Bookmark, EZ Search, Event, Museum, Snapshot, Timeline |
| Alarm Inputs/Outputs | 8 Inputs 2 Outputs |
| Event Trigger | Analytics, Motion |
| Power Consumption | Without HDD: 12 VDC at 4 A (15 W) |
| Operating Temperature | 14 to 122°F / -10 to 50°C |
| Certifications | NDAA *as per Manufacturer |
| Built-In Display | None |
| Dimensions (W x D x H) | 15.0 x 10.6 x 1.8″ / 380.0 x 268.0 x 45.0 mm |
