SMART Technologies MX2-V5-PW Overview
The SMART Technologies SMART Board MX (V5) Pro Series with IQ 55″ UHD 4K Touch Screen Commercial Monitor is a 300 nits bright interactive display with up to 40 points of accurate IR touch, Google EDLA certification, and a full suite of software including SMART Meeting Pro for enhanced annotation and collaboration in education spaces.
The user-friendly MX255-V5-PW is compatible with Windows, Mac, Chrome, and Android based devices. It supports multiple user profiles in a secure environment with NFC sign-in capability. Connect a wide variety of sources via HDMI, VGA, and OPS slot inputs, with USB-B for touch interactivity. Front and rear USB-C inputs provide full functionality over a single cable, including 65W power delivery. Multiple USB-A inputs are available to playback media files from USB storage devices, or connect peripherals, like a camera or keyboard. Additionally, a stereo speaker system and linear six-microphone array with support for onboard acoustic echo cancellation are built-in.
- Graphic organizers
- Interactive backgrounds
- Measurement tools
- Counters
- Fraction tiles
- Letter blocks
- Ready-made digital manipulatives for a variety of subjects, including money, time, math, reading, music, patterns, and more
- Multi-user support
- Google or Microsoft self-serve profile setup
- QR code and web link sign-in
- NFC sign-in
- Secure data protection
- Automatic over-the-air updating
- Split screen and picture-in-picture
- SMART Mirror screen share
- Whole class whiteboard
- Two-way inking, text, and interaction
- Built-in polling
- Integrated linear six-microphone array with support for onboard acoustic echo cancellation
- Wi-Fi 6E and hotspot support
- Bluetooth 5.2 dual mode
- Integrated stereo speaker system
Items Included
- SMART Technologies SMART Board MX (V5) Pro Series with IQ 55″ UHD 4K Touch Screen Commercial Monitor
- Power Cable
- USB-A to USB-B Cable (16’5″)
- USB-C Cable (6′)
- 2 x Interactive Pen
- 2 x External Wi-Fi & Bluetooth Antenna
- Remote Control
- 2 x AAA Battery for Remote
- Limited 3-Year Manufacturer Warranty
Additional Resources
User Manual
4.5 MB
SMART Technologies MX2-V5-PW Specs
| Display Size |
55″ |
| Native Resolution |
3840 x 2160 |
| Maximum Brightness |
300 nits / cd/m2 |
| Touchscreen |
Yes, Infrared (IR) |
| Inputs |
Front 1x HDMI 2.1 Rear 3x HDMI 2.1 1x DE-15/DB-15 (VGA) 1x 1/8″ / 3.5 mm (Analog Audio) |
| Outputs |
Rear 1x HDMI 2.1 1x 1/8″ / 3.5 mm (Analog Audio) 1x TOSLINK Optical (Digital Audio) |
| Wireless |
Wi-Fi 6E (802.11ax) / Bluetooth 5.2 |
| USB I/O |
Front 1x USB-C 3.0 / 3.1/3.2 Gen 1 (DisplayPort Alt Mode/Photo/Audio/Charging/Control/Touchscreen Control/Video) 2x USB-A 3.0 / 3.1/3.2 Gen 1 1x USB-B 3.0 / 3.1/3.2 Gen 1 (Touchscreen Control) Rear 1x USB-C 3.0 / 3.1/3.2 Gen 1 (DisplayPort Alt Mode/Photo/Audio/Charging/Control/Touchscreen Control/Video) 1x USB-A 2.0 2x USB-A 3.0 / 3.1/3.2 Gen 1 3x USB-B 3.0 / 3.1/3.2 Gen 1 (Touchscreen Control) |
| Ethernet I/O |
2x RJ45 Gigabit Ethernet |
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control Input |
| Built-In Speakers |
Yes, 2x 15 W |
| Media Card Reader |
1x microSD (Unspecified Type) |
| Display Size |
55″ |
| Panel Type |
LCD |
| Aspect Ratio |
16:9 |
| Display Orientation |
Landscape |
| Native Resolution |
3840 x 2160 |
| Maximum Brightness |
300 nits / cd/m2 |
| HDR Support |
No |
| Response Time |
8 ms |
| Refresh Rate |
60 Hz |
| Viewing Angle (H x V) |
178 x 178° |
| Finish |
Anti-Glare / Matte |
| Touchscreen |
Yes, Infrared (IR) |
| Multi-Touch Points |
40 |
| TV Tuner |
No |
| Inputs |
Front 1x HDMI 2.1 Rear 3x HDMI 2.1 1x DE-15/DB-15 (VGA) 1x 1/8″ / 3.5 mm (Analog Audio) |
| Outputs |
Rear 1x HDMI 2.1 1x 1/8″ / 3.5 mm (Analog Audio) 1x TOSLINK Optical (Digital Audio) |
| HDCP Support |
Yes, Version 2.3 |
| Wireless |
Wi-Fi 6E (802.11ax) / Bluetooth 5.2 |
| NFC |
Yes |
| USB I/O |
Front 1x USB-C 3.0 / 3.1/3.2 Gen 1 (DisplayPort Alt Mode/Photo/Audio/Charging/Control/Touchscreen Control/Video) 2x USB-A 3.0 / 3.1/3.2 Gen 1 1x USB-B 3.0 / 3.1/3.2 Gen 1 (Touchscreen Control) Rear 1x USB-C 3.0 / 3.1/3.2 Gen 1 (DisplayPort Alt Mode/Photo/Audio/Charging/Control/Touchscreen Control/Video) 1x USB-A 2.0 2x USB-A 3.0 / 3.1/3.2 Gen 1 3x USB-B 3.0 / 3.1/3.2 Gen 1 (Touchscreen Control) |
| Ethernet I/O |
2x RJ45 Gigabit Ethernet |
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control Input |
| Number of OPS/Expansion Slots |
1 |
| Ambient Light Sensor |
Yes |
| Multi-Input Support (PIP/PBP) |
Yes, Picture-in-Picture (PIP), Picture-by-Picture (PBP) |
| Built-In Speakers |
Yes, 2x 15 W |
| Speaker Configuration |
2-Channel |
| Smart TV |
Yes, Android 13.0 |
| CPU |
8-Core: |
| Storage |
64 GB |
| RAM |
8 GB DDR4 |
| OS Compatibility |
Computer: Windows / macOS / Chrome OS Mobile: Android/iOS |
| Media Card Reader |
1x microSD (Unspecified Type) |
| Built-In Mic |
Yes |
| Power Consumption |
Typical: 72.0 W Standby: 0.2 W |
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type |
Internal |
| Operating Conditions |
41 to 95°F / 5 to 35°C at 5 to 80% Humidity |
| Storage Conditions |
-4 to 140°F / -20 to 60°C |
| Certifications |
CB, CE, ENERGY STAR, FCC, HDCP, RCM, REACH, RoHS, UKCA, UL, WEEE |
| VESA Mounting-Hole Pattern |
400 x 400 mm |
| Lighting Lifespan |
50000 Hours |
| Dimensions |
51.2 x 32.2 x 3.8″ / 1301 x 818 x 96 mm |
| Weight |
70.5 lb / 32 kg |
| Package Weight |
95.2 lb |
| Box Dimensions (LxWxH) |
55.5 x 38 x 6.25″ |
