Smart-AVI SM-MST-2Q-S Overview
Connect and manage up to two systems from a single access point with the Smart-AVI SM-MST-2Q-S 2-Port Dual-Head DP MST KVM Switch. With features like front-panel keys and LEDs, USB 1.1 and 2.0 emulation and connectivity, support for resolutions up to 4K UHD (3840 x 2160 at 30 Hz), and RGB or YCbCr support, this KVM switch greatly benefits individuals looking to take greater control of their Windows 7 or 10 systems.
- DisplayPort 1.2a dual-mode receiver
- HDMI/DVI operation up to 320 MHz
- Max video input resolution 4K at 60 Hz
- Multi-Stream Transport supports up to two streams
- Supports RGB or YCbCr
- Supports balanced speakers output and switching
- External power supply – level VI efficiency
Items Included
- Smart-AVI SM-MST-2Q-S 2-Port Dual-Head DP MST KVM Switch
- 3.5mm to DB9 Cable
- 12 VDC, 2A Power Adapter with Center-Pin Positive Polarity
- Limited 1-Year Manufacturer Warranty
Additional Resources
Manual
1.2 MB
Smart-AVI SM-MST-2Q-S Specs
| # of Systems Supported |
2 |
| KVM I/O |
4x DisplayPort 2x USB-B 2x 1/8″ / 3.5 mm |
| Console I/O |
4x HDMI 2x USB-A 1x 1/8″ / 3.5 mm |
| Supported Resolutions |
3840 x 2160 @ 30 Hz |
| # of Systems Supported |
2 |
| KVM I/O |
4x DisplayPort 2x USB-B 2x 1/8″ / 3.5 mm |
| Console I/O |
4x HDMI 2x USB-A 1x 1/8″ / 3.5 mm |
| Supported Resolutions |
3840 x 2160 @ 30 Hz |
| USB Keyboard/Mouse Emulation |
Yes |
| OS Compatibility |
Windows 7 Windows 10 |
| Power Source |
AC Adapter |
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Consumption |
24 W |
| Cable Length |
20′ / 6.1 m |
| Certifications |
UL, CE, RoHS |
| Operating Conditions |
32 to 104°F / 0 to 40°C up to 80% Humidity |
| Storage Conditions |
-4 to 140°F / -20 to 60°C up to 80% Humidity |
| Operating Current |
2 A |
| Dimensions |
8.8 x 6.69 x 2.63″ / 22.4 x 16.99 x 6.68 cm |
| Weight |
3.85 lb / 1.75 kg |
