Sale!

Smart-AVI 4-Port Dual-Head DisplayPort KVM Switch With USB 2.0 And Audio(Smart Avi 4 Port Dual Head Displayport Kvm Switch With Usb 2 0 And Audio)

Smart-AVI 4-Port Dual-Head DisplayPort KVM Switch With USB 2.0 And Audio(Smart Avi 4 Port Dual Head Displayport Kvm Switch With Usb 2 0 And Audio) - Image 2

Smart-AVI 4-Port Dual-Head DisplayPort KVM Switch With USB 2.0 And Audio(Smart Avi 4 Port Dual Head Displayport Kvm Switch With Usb 2 0 And Audio)

Original price was: $374.00.Current price is: $99.99.

SKU: DGFUB 7075016474709 Categories: Computer & Presentation, Computer Peripherals, Computer Solutions Tags: Computer Peripherals, Computers, KVM Switches, Smart-AVI SM-DPN-4D-S

Elevate Your Shopping Experience
Product guarantee 100% satisfaction
The quality solution for all your needs.
Streamlined service, designed for your convenience.

Description
Reviews (0)

Smart-AVI SM-DPN-4D-S Overview

Easily manage and monitor four systems from a single convenient local setup with the Smart-AVI 4-Port Dual-Head DisplayPort KVM Switch with USB 2.0 and Audio. Whether you are an IT administrator, a creative designer, or business professional, this KVM gives you access to your systems and provides you with seamless switching when needed.

This unit supports four systems with DisplayPort video output at a maximum resolution of 3840 x 2160 with a 30 Hz refresh rate for a clear and smooth image. EDID Learn technology remembers the settings of your display to ensure you are getting the best possible view of your work every time you turn your systems on. Connect your peripherals, such as mice, keyboards, and more, with USB 2.0 connectivity to manage information with ease. Transfer audio, including notifications or alerts, via 3.5mm jacks, and connect speakers or a headset to the KVM. You can easily switch systems using the front-panel push summary or keyboard hotkeys.

Keyboard & Mouse Emulation

Keyboard and mouse emulation mimics the connection between a computer and your devices to keep your equipment in constant connection. This prevents the connected systems from accidentally disconnecting your devices and prompting a system reset.

Dual-Head Design

Support for multiple displays with dual-head design allows you to expand your system’s screen real estate so you can work on more complex programs per system.

RS-232 Serial Commands

For advanced control methods, you can use various RS-232 commands with terminal applications.

UPC: 657477086275

Items Included

Smart-AVI 4-Port Dual-Head DisplayPort KVM Switch with USB 2.0 and Audio
Power Supply
Limited 1-Year Manufacturer Warranty

Additional Resources

Manual

2.5 MB

Smart-AVI SM-DPN-4D-S Specs

Key Specs

# of Systems Supported	4
KVM I/O	4x DisplayPort 4x USB-B 4x 1/8″ / 3.5 mm
Console I/O	2x DisplayPort 2x USB-A (Keyboard/Mouse) 2x USB-A 1x 1/8″ / 3.5 mm
Supported Resolutions	3840 x 2160 @ 30 Hz

General

# of Systems Supported	4
KVM I/O	4x DisplayPort 4x USB-B 4x 1/8″ / 3.5 mm
Console I/O	2x DisplayPort 2x USB-A (Keyboard/Mouse) 2x USB-A 1x 1/8″ / 3.5 mm
Supported Resolutions	3840 x 2160 @ 30 Hz
USB Keyboard/Mouse Emulation	Yes
OS Compatibility	Windows macOS Linux

Power

Power Source	AC Adapter
Input Power	100 to 240 VAC, 50 / 60 Hz
Power Consumption	24 W

Physical

Certifications	CE, RoHS, UL
Operating Conditions	32 to 104°F / 0 to 40°C up to 80% Humidity
Storage Conditions	-4 to 140°F / -20 to 60°C
Dimensions	12.57 x 6.69 x 2.7″ / 31.93 x 16.99 x 6.9 cm
Weight	4.2 lb / 1.9 kg
