Sharp PX2201UL Overview
John Foldi
Corporate retail signage, guest simulations, and theme park attractions are just some of the uses of the powerful NP-PX2201UL 21,500-Lumen WUXGA Laser DLP Projector from NEC. The NP-PX2201UL does not come with a lens, letting you customize it to suit your specific optical needs. Once setup, your presentations will enjoy a DLP projection system for superb contrast, a crisp HD 1920 x 1200 resolution image, all at an enormous 21,5000-lumen brightness suitable for daylight use. Multiple motorized lens adjustments make image adjustment a breeze, and many features are included to simply management, display content in varied and engaging ways, and ensure a long, nearly maintenance-free lifespan.
- Vertical and horizontal lens shift
- Quick start up lets you start presenting in as little as 3 to 4 seconds
- Quick power off lets you shut down without waiting for the unit to cool down
- Supports 24/7 operation
Items Included
- Sharp NP-PX2201UL 21,500-Lumen WUXGA Laser DLP Projector (No Lens)
- Remote Control with Batteries
- Power Cord
- Cable Cover
- Lens Hole Cap
- Lens Anti-Theft Screw
- Security Sticker
- Limited 55-Year Manufacturer Warranty (5 Years or 20,000 Hours)
Not Included
- Essential Lenses & Lens Adapters
Additional Resources
User Manual
4.0 MB
Sharp PX2201UL Specs
| Display System |
0.96″ DMD DLP |
| Native Resolution |
1920 x 1200 |
| Maximum Brightness |
21,500 Lumens (Center) |
| HDR Support |
No |
| Inputs/Outputs |
2x HDMI 2.0 Audio, Video Input 1x DisplayPort 1.4 Audio, Video Input 1x RJ45 (HDBaseT) Audio, Control, Video Input/Output 1x DVI-D 1.4 Video Input 1x DE-15/DB-15 (VGA) Video Input 1x 5BNC Video Input |
| Light Source |
Laser Phosphor |
| Display System |
0.96″ DMD DLP |
| Native Resolution |
1920 x 1200 |
| Supported Resolutions |
Maximum: 2560 x 1600 Minimum: 640 x 480 |
| Maximum Brightness |
21,500 Lumens (Center) |
| Aspect Ratio |
Native: 16:10 |
| Contrast Ratio |
10,000:1 |
| Scan |
Horizontal: 15 to 153 kHz Vertical: 24 to 120 Hz |
| Includes Lens |
No |
| Keystone Correction |
Horizontal: ± 60° Vertical: ± 40° |
| HDR Support |
No |
| Multi-Input Support (PIP/PBP) |
Picture-in-Picture (PIP), Picture-by-Picture (PBP) |
| Ceiling Mountable |
Yes |
| Inputs/Outputs |
2x HDMI 2.0 Audio, Video Input 1x DisplayPort 1.4 Audio, Video Input 1x RJ45 (HDBaseT) Audio, Control, Video Input/Output 1x DVI-D 1.4 Video Input 1x DE-15/DB-15 (VGA) Video Input 1x 5BNC Video Input |
| HDCP Support |
Yes, Version 2.2 |
| Media/Memory Card Slot |
No |
| Mobile App Compatible |
No |
| Wireless LAN / Wi-Fi |
No |
| Bluetooth |
No |
| Light Source |
Laser Phosphor |
| Expected Lamp Life |
Full Brightness: 20,000 Hours |
| Fan Noise |
Full Brightness: 48 dB Low Brightness: 46 dB |
| Input Power |
200 to 240 VAC, 50 Hz |
| Power Consumption |
Full Brightness: 1775 W |
| Operating Temperature |
32 to 104°F / 0 to 40°C |
| Storage Temperature |
-4 to 140°F / -20 to 60°C |
| Operating Humidity |
10 to 85% |
| Storage Humidity |
10 to 85% |
| Dimensions (W x H x D) |
1.7 x 0.8 x 2.5′ / 530.0 x 248.0 x 748.0 mm |
| Weight |
112.4 lb / 51 kg |
