- Broadcom BCM2837B0, Cortex-A53 64-bit SoC @ 1.4 GHz
- 512MB LPDDR2 SDRAM
- 2.4GHz/5GHz 802.11 b/g/n Wireless LAN
- Bluetooth Low Energy 4.2 (BLE)
- Full Size HDMI, MIPI DSI Display Port, MIPI CSI Camera Port
- 4-Pole stereo audio/composite video jack
- MicroSD Card for OS and data storage
- 5V, 2.5A DC power supply via micro USB or GPIO
Applications
Embedded Design & Development, Electronics Design, Hobby & Education, Communications & Networking, Consumer Electronics, IoT (Internet of Things), Industrial
Footnotes
Product details
| SOC Type:
Broadcom BCM2837B0 |
| Core Type:
64-bit ARM Cortex-A53 |
| No. of Cores:
4Cores |
| GPU:
VideoCore IV |
| CPU Speed:
1.4GHz |
| USB Ports:
USB 2.0 x 1 |
| HDMI Ports:
Full Size HDMI x 1 |
| Product Range:
Raspberry Pi 3 Model A+ |
| Audio / Video Interface:
3.5mm Audio Jack |
| General Purpose I/O:
40Pins |
| Display Interface:
Supported |
| Memory Card Support:
microSD |
| Camera Interface:
Supported |
| Wi-Fi Connectivity:
Supported 2.4GHz and 5GHz 802.11 b/g/n/ac |
| Bluetooth Connectivity:
Bluetooth 4.2 BLE |
| Power Inlet:
microUSB, GPIO |
Other details
| Brand | RASPBERRY-PI |
| Part Number | RPI3-MODAP |
| Quantity | Each |
| Technical Data Sheet EN |
