OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb)

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb) - Image 2

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb) - Image 3

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb) - Image 4

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb) - Image 5

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb) - Image 6

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb) - Image 7

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 X 8TB)(Owc Node Titan Se 72tb 9 Bay Thunderbolt 3 Raid Array 9 X 8tb)

Original price was: $374.00.Current price is: $99.99.

SKU: DGFUB 7075059073109 Categories: Computer & Presentation, Computer Solutions, Drives & Storage Tags: Computers, Drives Storage, Hard Drive Arrays, OWC Node Titan SE External SSD

Elevate Your Shopping Experience
Product guarantee 100% satisfaction
The quality solution for all your needs.
Streamlined service, designed for your convenience.

Description
Reviews (0)

OWC Node Titan SE External SSD Overview

Designed for DITs, productions, editors, and other creative professionals, the Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array from OWC / Other World Computing delivers massive amounts of external storage in a chassis that can be conveniently moved around between on-location work, editing studios, or even shipped to a post facility. Built to handle VFX, multicam 4-6K, 8-12K raw video, 360° VR content, and more this Titan SE has a storage capacity of 72TB, which comes in a 9 x 8TB NVMe PCIe M.2 2280 configuration. It supports software-controlled RAID 0, 1, 4, 5, and 1+0 (10), each of which provides performance, data redundancy, or a combination of both. Preformatted as RAID 0 for Mac, the Titan SE can achieve data transfer speeds of up to 2926 MB/s. When configured as RAID 5, it can achieve speeds of up to 2477 MB/s.

While the Node Titan SE comes preformatted for Mac, it may be reformatted for use with Windows. It connects to your host system using a 40 Gb/s Thunderbolt 3 port that provides up to 85W of charging power.

Please note that SoftRAID only works with Windows 11 or macOS 10.14 or later. Also, while SoftRAID serial numbers work on both Windows and Mac, SoftRAID is licensed per computer. In order to use SoftRAID on multiple computers, you will need a unique, valid license per computer. Lastly, RAID 4 and 1+0 (10) are currently only available for Mac.

Max Your Mac Studio

For all its wonderous capabilities, the Mac Studio has a couple of shortcomings. The internal storage is limited to a max of 8TB as a factory option and isn’t upgradeable. There aren’t any PCIe expansion slots to add a storage card. Whatcha gonna do when your projects’ capacity requirements come for you? You need the biggest, baddest capacity solution in the land to get the max usefulness from your Mac Studio.

Designed for Those That Need More

OWC’s team is filled with creatives highly experienced in all phases of the video production world. They get your need for more speed and capacity when it comes to everything from backup to editing. The Node Titan SE is a Simply Elegant portable problem-solver for pros like you that need more from their storage:

DITs and productions needing a shuttle drive that can be easily shipped while also offering performance and reliability.
Professional video editors wanting a seamless editing experience with a drive capable of storing up to 72TB of data to have all the files centralized and easily accessible while editing.
Creative professionals working with cutting edge workflows such as VFX, multicam 4-6K, 8-12K RAW video, 360° VR content looking for ultra high-capacity storage with the best possible performance when using an external storage solution.

Beyond Hardware RAID

SoftRAID provides a level of storage performance that you simply can’t get with hardware RAID. SoftRAID gives you increased power and control over your RAID drives and disks that hardware RAID can’t deliver and doesn’t lock you into technology that you can’t upgrade or expand.

The RAID 5 Problem Solver

Using RAID 5 in the past meant giving up precious capacity and taking a big hit on performance. The Node Titan SE solves that problem by offering up to 64TB of useable storage while nearly maxing out the Thunderbolt 40 Gb/s limits with speeds up to 2477 MB/s. Now you can streamline ingestion and backup times on set, edit ultra high-res multi-cam sequences, and adhere to mandatory requirements (the 3-2-1 Principle) when producing content for large studios such as Netflix.

Powerfully Unlimited

You can work without limits when you add the Node Titan SE to your workflow. There’s a built-in power supply to keep your workspace free from the bulk and clutter of a power brick. If you’re using a notebook, you can charge its battery while pushing your creativity and machine to the limit. No more separate power adapter needed, just connect the Node Titan’s 85W Thunderbolt upstream port to your notebook via the included Thunderbolt 3 cable and you’re set.

SoftRAID: RAID Made Easy

Harness the full capability of your OWC drive array with the included SoftRAID XT, a powerful, intuitive RAID management software for macOS and Windows. SoftRAID’s RAID creation and management technology has been finely tuned to perfection with over 20 years of development to provide rock solid protection of your data and optimize drive performance.

SoftRAID XT provides an unbeatable combination of speed, protection, and compatibility:

Advanced: Create RAID 0/1/4/5/1+0 (10) arrays
Protected: SoftRAID Monitor constantly watches your disks and alerts you if problems are detected
Validated: Volume validation ensures sectors can be read and parity is correct
Certified: Checks disks before use to ensure they are safe for data storage
Vigilant: Error prediction helps protect against unexpected failure
Universal: Move SoftRAID arrays seamlessly between Mac and PC2 with built-in OWC MacDrive technology

OWC Thunderbolt Cable Included

OWC Node Titan SE solutions come with a certified 29″ OWC Thunderbolt (USB-C) Cable. But if your workflow demands a different length to make the connection, OWC Thunderbolt (USB-C) Cables are a great choice.

UPC: 810149208188

Items Included

OWC Node Titan SE 72TB 9-Bay Thunderbolt 3 RAID Array (9 x 8TB)
Thunderbolt 3 Cable (29″)
Power Cable
Ballistic Hard-Shell Travel Case
3-Year OWC SoftRAID XT Upgrade and Support Plan
Limited 3-Year Manufacturer Warranty

Additional Resources

No additional resources available

OWC Node Titan SE External SSD Specs

Key Specs

Storage Capacity	72 TB
Included Drives	9x 8 TB SSD
RAID	Yes, Supported RAID Modes: 10 / 4 / 5 / 0 / 1 (Preconfigured in RAID 0)
Inputs/Outputs	1x USB-C Thunderbolt 3 (40 Gb/s)

Computing

Bridge Chipset

Intel JHL7440

Drives

Storage Capacity	72 TB
Included Drives	9x 8 TB SSD
RAID	Yes, Supported RAID Modes: 10 / 4 / 5 / 0 / 1 (Preconfigured in RAID 0)
Transfer Rates	2926 MB/s (RAID 0) 2477 MB/s (RAID 5) 2828 MB/s (Read) 2822 MB/s (Write)

General

Inputs/Outputs	1x USB-C Thunderbolt 3 (40 Gb/s)
Media Card Slots	No

Software

OS Compatibility	Windows 11 Windows 10 (64-Bit Only) macOS 10.14 to 14
Default OS Support	macOS

Security

Encryption	No
Security Features	No

Electrical

Input Power	100 to 240 VAC, 60 / 50 Hz at 5 to 10 A
PSU Wattage	1 x 650 W

Physical

Operating Conditions	50 to 95°F / 10 to 35°C at 8 to 90% Humidity
Storage Conditions	-40 to 149°F / -40 to 65°C at 5 to 95% Humidity
Certifications	CE, FCC, RoHS, VCCI, RCM, BSMI
Cooling	1x Fan
Material of Construction	Aluminum
Cable Length	29″ / 0.7 m
Dimensions	14.1 x 10.5 x 5.3″ / 35.8 x 26.7 x 13.5 cm
Weight	7.7 lb / 3.5 kg
