Optoma Technology ZU2200 18,500-Lumen WUXGA Laser DLP Projector (No Lens)(Optoma Technology Zu2200 18 500 Lumen Wuxga Laser Dlp Projector No Lens)

Professional Quality and Reliability

Strong reliability is at the core of the ZU2200 projector, with 24/7 operation capabilities, up to 30,000 hours of laser lifetime, and an IP5X rating for optimal and dependable performance, even under more extreme conditions up to 122°F. With a robust metal chassis and modular design for easier maintenance, a multitude of connectivity options, and failsafe redundancy mode for instant source switching, the ZU2200 projector offers a solution for intricate installations, including multi-projector and dome projection applications.

Brightness

The ANSI lumen brightness for the ZU2200 projector is 18,500 lumens. The manufacturer has provided their own specification of 22,000 lumens.

Multicolor Laser

Innovative Multicolor Laser (MCL) technology adds a second red laser to the common blue laser. This results in greatly improved color performance.

Input Failover with Fast Switching

The unique signal input detection function provides instant source switching in the event of the failure of the signal source device. This feature ensures an image never fails to display in mission critical installations such as control rooms, live events, or other similar scenarios.

Integrated Warping and Edge Blending

An integrated warping and edge blending processor enables multiple projectors to be warped and blended without additional dedicated hardware, reducing the cost and complexity of installation. Warping and edge blending is configured using either the projectors on screen display or with PC software depending on model.

Auto Color Uniformity and Focus

Providing a quick, hassle free and more convenient setup; you can enjoy a crystal-clear image with accurate color uniformity in a matter of seconds with the super-fast camera-based auto color uniformity and auto focus features. These features are compatible with image sizes up to 300″ diagonally.

HDBaseT

HDBaseT input compatibility provides uncompressed Full HD video, audio, network, and control commands, all delivered on a single CAT-type cable. HDBaseT is typically capable of transmitting signals up to 328 feet without loss making installation hassle-free. HDBaseT simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.

Integrator Friendly Control

The ZU2200 features a wide range of options to control and monitor the projector remotely.

• RS232: Optoma projectors come with an extensive set of RS232 commands making it simple and easy to manage using any control system.
• AMX compatible: Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.
• Crestron RoomView: Using the compatible RoomView software you can power on/off, monitor, manage, and control up to 250 projectors at the same time from any computer.
• Extron IPLink compatible: Allows for easy installation with Extron control systems.
• PJLink: Allows for easy installation with PJLink compatible control systems.
• Telnet: This model can receive commands via telnet allowing for easy installation with Telnet compatible control systems.

Additional Features

• 4K and HDR compatible
• Color Management System (CMS) allows you to fine tune the color settings
• Manage power for longest life, brightest picture, or anywhere in between
• Constant brightness helps maintain consistent brightness levels over time for long running installations
• True AV mute gives 100% screen blackout with instant on and off
• Full lens shift
• Picture-by-picture, picture-in-picture
• Active and Passive full 3D capability
• Wired remote control option

Optoma Technology ZU2200 Specs

Display System	DLP
Native Resolution	1920 x 1200
Maximum Brightness	18,500 Lumens (ANSI) 22,000 Lumens
HDR Support	Yes
Inputs/Outputs	2x HDMI Audio, Video Input 1x RJ45 (HDBaseT) Audio, Control, Data, LAN, Remote, Video Input 1x DisplayPort Video Input 1x DE-15/DB-15 (VGA) Video Input 1x DVI-D Video Input 1x BNC (3G-SDI) Video Input 1x HDMI Video Output 1x BNC (3G-SDI) Video Output 1x DE-9/DB-9 (RS-232) Control Input 1x BNC (VESA 3D Sync) Control Input 1x 1/8″ / 3.5 mm Mini Remote Input 1x DE-9/DB-9 (RS-232) Control Output 1x BNC (VESA 3D Sync) Control Output 1x 1/8″ / 3.5 mm Mini Remote Output 1x RJ45 (Ethernet) LAN Input 1x USB-A Service Input
Light Source	Laser Phosphor

Display System	DLP
Native Resolution	1920 x 1200
Supported Resolutions	Maximum: 4096 x 2160 @ 60 Hz
Maximum Brightness	18,500 Lumens (ANSI) 22,000 Lumens
Aspect Ratio	Native: 16:10 Supported: 16:9
Dynamic Contrast Ratio	2,000,000:1
DLP Link 3D	Yes
Supported 3D Formats	Frame Sequential Frame Packing Side by Side Top Bottom

Includes Lens

No

Keystone Correction	Vertical: ± 40° Horizontal: ± 40°
HDR Support	Yes
Digital Zoom	4x
Multi-Input Support (PIP/PBP)	Picture-in-Picture (PIP), Picture-by-Picture (PBP)
Ceiling Mountable	Yes
Rear Screen Projection	Yes
Built-In Speaker	No
Projection Tilt Option	Yes

Inputs/Outputs	2x HDMI Audio, Video Input 1x RJ45 (HDBaseT) Audio, Control, Data, LAN, Remote, Video Input 1x DisplayPort Video Input 1x DE-15/DB-15 (VGA) Video Input 1x DVI-D Video Input 1x BNC (3G-SDI) Video Input 1x HDMI Video Output 1x BNC (3G-SDI) Video Output 1x DE-9/DB-9 (RS-232) Control Input 1x BNC (VESA 3D Sync) Control Input 1x 1/8″ / 3.5 mm Mini Remote Input 1x DE-9/DB-9 (RS-232) Control Output 1x BNC (VESA 3D Sync) Control Output 1x 1/8″ / 3.5 mm Mini Remote Output 1x RJ45 (Ethernet) LAN Input 1x USB-A Service Input
HDCP Support	Yes
Media/Memory Card Slot	No

Mobile App Compatible	No
Wireless LAN / Wi-Fi	No
Bluetooth	No

Light Source	Laser Phosphor
Expected Lamp Life	Low Brightness: 30,000 Hours
Fan Noise	Full Brightness: 40 dB
Security	Cable Lock Slot Password Protection
Supported Languages	Dutch English French German Hungarian Italian Japanese Korean Norwegian Polish Portuguese Russian Simplified Chinese Spanish Thai Traditional Chinese
Input Power	100 to 240 VAC, 50 / 60 Hz
Power Consumption	Full Brightness: < 1200 W Low Brightness: 590 W Standby Mode (Lamp Off): < 0.5 W
Certifications	FCC Class A, Part 15, ICES-003, RoHS, WEEE
Operating Conditions	32 to 122°F / 0 to 50°C at 10 to 85% Humidity
Storage Conditions	14 to 140°F / -10 to 60°C at 5 to 90% Humidity
Dimensions (W x H x D)	25.6 x 11.8 x 26.9″ / 650.0 x 300.9 x 682.0 mm (with Feet, without Lens) 25.6 x 9.9 x 26.9″ / 650.0 x 251.0 x 682.0 mm (without Feet, without Lens)
Weight	119.05 lb / 54 kg
