NXP PCA9846PW-ARD PCA9846PW-ARD Evaluation Board PCA9846 I2C 1 MHz I.MX 8M Mini LPDDR4 EVK(Nxp Pca9846pw Ard Pca9846pw Ard Evaluation Board Pca9846 I2c 1 Mhz I Mx 8m Mini Lpddr4 Evk)

PCA9846PW-ARD evaluation board is an expansion card equipped with an Arduino port. The board is designated for easy testing and design of the PCA9846 IC. PCA9846 IC has a four-channel ultra-low voltage, FM+ I2C-bus switch with reset. The board is fully compliant with IMXRT1050 EVK, LPCXpresso55S69 (LPC55S69-ECK) and i.MX 8M Mini LPDDR4 EVK (8MMINILPD4-EVK, 8MMINID4-EVK), including GUI software control. The board can be attached to any device equipped with Arduino port.

• Equipped with four I2C EEPROMs for rapid test and measurements
• Equipped with programmable power supply for logic level combination
• On-board I2C-bus external connector (channel 3 and 4)
• Equipped with Arduino Uno R3 port for direct connection with Arduino devices
• Fully compliant with IMXRT1050 EVK board, including GUI (Windows 10)
• Fully compliant with LPCXpresso55S69 development board, including GUI (Windows 10)
• Allows bidirectional voltage-level translation and I2C-bus switch

Contents

PCA9846PW-ARD Arduino shield, Quick start guide.

Product details

Silicon Manufacturer	NXP
Core Architecture	–
Core Sub-Architecture	–
Silicon Core Number	PCA9846
Silicon Family Name	–
For Use With	NXP IMXRT1050 EVK Board, LPCXpresso55S69 Development Board, i.MX 8M Mini LPDDR4 EVK Board
Kit Contents	Arduino Shield, Quick Reference Card
Product Range	–

Other details

Brand	NXP
Part Number	PCA9846PW-ARD
Quantity	Each
Technical Data Sheet EN
User Manual EN
