Sale!

Netgear MS108EUP 8-Port PoE+ / PoE++ Complaint 2.5G Managed Network Switch(Netgear Ms108eup 8 Port Poe Poe Complaint 2 5g Managed Network Switch)

Netgear MS108EUP 8-Port PoE+ / PoE++ Complaint 2.5G Managed Network Switch(Netgear Ms108eup 8 Port Poe Poe Complaint 2 5g Managed Network Switch) - Image 2

Netgear MS108EUP 8-Port PoE+ / PoE++ Complaint 2.5G Managed Network Switch(Netgear Ms108eup 8 Port Poe Poe Complaint 2 5g Managed Network Switch)

Original price was: $341.00.Current price is: $96.99.

SKU: DGFUB 6950342688853 Categories: Computer & Presentation, Computer Solutions, Networking Tags: Bridges & Hubs, Computers, Netgear MS108EUP-100NAS, Network Switches

Elevate Your Shopping Experience
Product guarantee 100% satisfaction
The quality solution for all your needs.
Streamlined service, designed for your convenience.

Description
Reviews (0)

Netgear MS108EUP-100NAS Overview

1Description
2Versatile Mounting
3Silent Operation
4Advanced PoE Controls
5Easy Management
6Link Aggregation

Enhance your business by supporting Wi-Fi 6 access points, advanced IP security cameras, VoIP phones, and other power-over-Ethernet devices with the Netgear MS108EUP 8-Port PoE+ / PoE++ Complaint 2.5G Managed Network Switch. Designed for strong performance and easy management, this switch features eight 2.5G Ethernet ports, four of which support 30W PoE+ power while the other four can operate 60W PoE++ compatible devices with a total power budget of 230W. The easy-to-use web-based interface allows you to manage PoE prioritization, scheduling, per-port power limits and more. At the same time, the 40 Gb/s non-blocking switching capacity helps to ensure smooth performance for multimedia broadcasts and other high-bandwidth applications.

Versatile Mounting

Place the MS108EUP network switch on a desktop or mount it onto a wall with the included kit.

Silent Operation

The all-metal, fanless design efficiently dissipates heat without disrupting your environment.

Advanced PoE Controls

Manage PoE prioritization, scheduling, power limit per port, and more for simple control over all PoE-powered devices.

Easy Management

Simply plug the MS108EUP and configure it using the web-based interface.

Link Aggregation

Maximize your bandwidth with compatible devices by combining up to four ports, with a maximum of four link aggregation groups.

UPC: 606449156942

In the Box

Netgear MS108EUP 8-Port PoE+ / PoE++ Complaint 2.5G Managed Network Switch
Power Adapter & Cable
Wall Mount Kit
Rubber Feet
Lifetime Next Business Day Hardware Replacement.
ProSUPPORT 24×7 Advanced Technical Support via Phone (90 Days)
ProSUPPORT Lifetime 24×7 Advanced Technical Support via Chat
Limited Lifetime Warranty

User Manual

0.8 MB

Table of Contents

Description
Versatile Mounting
Silent Operation
Advanced PoE Controls
Easy Management
Link Aggregation

Netgear MS108EUP-100NAS Specs

Wi-Fi

None

Interfaces

Inputs/Outputs

4 x 2.5 Gb/s Ethernet (RJ45) PoE+
4 x 2.5 Gb/s Ethernet (RJ45) PoE (Type 3)

Protocols

Layer Services Supported	Layer 2 Support
Supported Protocols	IGMP Snooping Link Aggregation
Queuing	Weighted Round Robin (WRR)
Transmission Method	Store-and-Forward
Jumbo Frames Support	12,000 Bytes
MAC Address Table Size	16K
Multicast Groups	128
VLAN Groups	64

Security

Security Features

DoS Attack Prevention

Standards

Supported IEEE Standards

802.1q, 802.3, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3bt, 802.3bz, 802.3p, 802.3u, 802.3x

Performance

Switching Bandwidth	40 Gb/s (Non-Blocking)
Packet Buffer	1.5 MB

Electrical

PoE Power Budget	230 W
PoE per Port	30 to 60 W
Power Supply Type	External

Environmental

Operating Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	90%
Storage Temperature	-4 to 158°F / -20 to 70°C
Storage Humidity	95%
Operating Altitude	10,000′ / 3048 m
Storage Altitude	10,000′ / 3048 m

General

Cooling System	Passive
Mean Time Between Failures (MTBF)	373,644 Hours
Material of Construction	Metal
Indicator Lights	Link/Activity/Speed, PoE, Power
Dimensions	8.3 x 5.5 x 1.6″ / 210 x 140 x 40 mm
Weight	2 lb / 0.9 kg

Packaging Info

Package Weight	5.285 lb
Box Dimensions (LxWxH)	10.9 x 9.4 x 3.7″
