Netgear GS728TP 24-Port Gigabit PoE+ Compliant Managed Network Switch(Netgear Gs728tp 24 Port Gigabit Poe Compliant Managed Network Switch)
Original price was: $336.00.$98.99Current price is: $98.99.
- Elevate Your Shopping Experience
- Product guarantee 100% satisfaction
- The quality solution for all your needs.
- Streamlined service, designed for your convenience.
Netgear GS728TP-300NAS Overview
Grow your business’s network to support IP security cameras, access points, VoIP phones, and other power-over-Ethernet compatible devices with the Netgear GS728TP 24-Port Gigabit PoE+ Compliant Managed Network Switch. This rack mountable managed network switch features 24 Gigabit Ethernet ports, each capable of providing up to 30W PoE+ to compatible devices with a total power budget of 190W. There are also four Gigabit SFP ports available for fiber uplinks.
With a 56 Gb/s switching capacity and 41.67 Mpps forwarding rate, the GS728TP is ready for applications such as video streaming and multicast traffic. It also protects your network from threats, including Denial of Service (DoS) attacks. You can configure, manage, and monitor your network locally using the web browser interface or through the cloud-based Netgear Insight management platform. A 1-year subscription to Insight is included.
IEEE 802.3x Flow Control
Dynamic MAC address management
IEEE 802.1Q-based VLAN
Auto Voice VLAN
Auto Video VLAN (selected models)
VLAN routing (selected models)
QoS based on WRR, strict priority, or both
Port-based and IEEE 801.2p-based QoS
TCP/UDP-based QoS
DiffServ
IPv4 and IPv6-based QoS (selected models)
DSCP Support
Rate Limiting (ingress, or egress)
Link Aggregation and LACP
Smart Lite CLI Software for multi-switch management
IP Access List
IPv6 Management
Configurable Management VLAN
SNMP v1/v2c and v3
Standard MIBs (RFC1213, RFC1643, and RFC1493)
RMON group 1, 2, 3, 9
Firmware download (to switch) and upload (to server) through TFTP/HTTP
Configuration and Image Upload (to PC) through HTTP
Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)
Memory & FLASH log
Syslog (server)
System password protection
MAC lockdown by number of MACs
IEEE 802.1x port authentication (EAP) – MD5: FS728TPv2, FS728TLP, GS108Tv2, GS110TP, GS510TP
IEEE 802.1x port authentication – EAP: GS510TLP, GS510TPP, GS418TPP, GS516TP, GS716Tv3, GS724Tv4, GS748Tv5, GS724TPv2, GS728TP, GS728TPv2, GS728TPP, GS728TPPv2, GS752TP, GS752TPv2, GS752TPP
Dynamic VLAN Assignment
Guest VLAN
TACACS+
3 HTTPS /SSL versions (except FS728TLP)
TLS session (except FS728TLP)
Trusted MAC
IPv4, L4-based Access Control List (ACL)
IPv6-based ACL (selected models)
IGMP snooping querier
Blocking of unknown multicast traffic
Option to enable/disable BPDU flooding when STP is disabled
Static routing with 32 static routes (Selected models)
Hosted ARP table size of 512 (Selected models)
Jumbo frame support
Broadcast Storm control
Cable diagnostics
Loop Detection
DoS Prevention
IEEE 802.1ab LLDP
LLDP-MED
Dual Image
SNTP
Option to enable/disable the flooding of EAPOL when 802.1x is disabled
Protected ports
DNS client (except FS728TLP)
DHCP clients
DHCP snooping (except FS728TLP)
Ping and traceroute client (except FS728TLP)
Items Included
- Netgear GS728TP 24-Port Gigabit PoE+ Compliant Managed Network Switch
- Power Cable
- Rackmount Kit
- Rubber Footpads
- 90-Day Technical Support via Phone
- Limited Lifetime Next Business Day Hardware Replacement
- Limited Lifetime Online Chat Technical Support
- Limited Lifetime Warranty
Additional Resources
User Manual
3.0 MB
Netgear GS728TP-300NAS Specs
| Inputs/Outputs |
24x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at) 4x SFP Gigabit Ethernet |
| Stackable |
No |
| Switching Bandwidth |
56 Gb/s |
| PoE Power Budget |
190 W |
| Stackable |
No |
| Layer Services Supported |
Layer 2, Layer 3, Layer 4 |
| Supported Protocols |
Auto-VoIP DHCP Server IGMP Snooping IPv4 IPv6 RADIUS |
| Queuing |
Weighted Round Robin (WRR) |
| Jumbo Frames Support |
10,000 Bytes |
| MAC Address Table Size |
16K |
| Multicast Groups |
512 |
| Security Features |
DHCP Snooping RADIUS Authentication Storm Control |
| Latency |
8.3 to 8.6 µs |
| Forwarding Rate |
41.67 Mpps |
| Switching Bandwidth |
56 Gb/s |
| Priority Queues |
8 |
| Packet Buffer |
1.5 MB |
| Flash Memory |
64 MB |
| CPU |
Single-Core: Up to 0.8 GHz |
| Memory |
512 MB |
| PoE Power Budget |
190 W |
| Power Draw |
226.00 W (Max) |
| Power Supply Type |
Internal |
| Certifications |
CE, FCC, RCM, ICES, VCCI, KC, BSMI, UKCA, CB, CSA |
| Noise Level |
39.3 dB |
| Cooling System |
Fan |
| Indicator Lights |
Yes |
| Rack Mountable |
Yes |
| Dimensions |
17.3 x 10.1 x 1.7″ / 439.4 x 256.5 x 43.2 mm |
| Weight |
8.32 lb / 3.77 kg |
| Package Weight |
10.115 lb |
| Box Dimensions (LxWxH) |
20.4 x 9.6 x 3.9″ |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
