MSI MAG B550 TOMAHAWK Overview
MSI MAG B550 TOMAHAWK Specs
| Chipset | AMD B550 |
| CPU Socket | AM4 |
| USB | 1 x USB-C (USB 3.2 Gen 2×2) 1 x USB-A (USB 3.1/3.2 Gen 2) 2 x USB-A (USB 3.0 / 3.1/3.2 Gen 1) 2 x USB-A (USB 2.0) |
| Thunderbolt | None |
| Display | 1 x DisplayPort 1 x HDMI 2.1 |
| Audio | 5 x 1/8″ / 3.5 mm 1 x S/PDIF |
| Ethernet / Controller | 1 x Realtek RTL8125B 2.5Gigabit 1 x Realtek RTL8111H Gigabit |
| PS/2 | 1 x Combo |
| Buttons | BIOS Flashback |
| Memory Slots | 4 x 288-Pin |
| Memory Support | DDR4 1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 4866, 5000, 5100 MHz |
| Maximum Capacity | 128 GB |
| Channel Architecture | Dual Channel |
| ECC Support | Non-ECC, ECC Unbuffered |
| SATA | 6 x SATA III |
| M.2 | 1 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4) 1 x M Key 2242, 2260, 2280 (PCIe 3.0 x4) |
| Optane Memory Support | No |
| RAID Support | RAID 0, 1, 10 (SATA) RAID 0, 1 (M.2) |
| Expansion Slots | 2 x PCIe 3.0 x1 |
| USB | 1 x 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-C Port) 1 x 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-A Port) 2 x 2.0 Header (Supports 4 USB-A Port) |
| Multi-GPU Support | AMD CrossFireX |
| Air Cooling | 1 x 4-Pin CPU 6 x 4-Pin System |
| Liquid Cooling | 1 x 4-Pin Pump |
| Power Connectors | 1 x 24-Pin Mainboard 1 x 8-Pin ATX |
| Security | Chassis Intrusion, TPM Module |
| LED Header | 4 x RGB |
| Audio | 1 x S/PDIF |
| Diagnostics | Clear CMOS |
| Front Panel I/O | AAFP |
| Audio Codec | Realtek ALC1200 / ALC1220P (7.1-Channel) |
| Bluetooth | None |
| Wi-Fi | None |
| OS Compatibility | Windows 10 (64-Bit Only) *As of July, 2022: Check with manufacturer for the most up-to-date compatibility |
| Form Factor | ATX |
| Dimensions | 12.0 x 9.6″ / 30.5 x 24.4 cm |
| Package Weight | 3.84 lb |
| Box Dimensions (LxWxH) | 14.1 x 11.2 x 2.9″ |
