Listen Technologies Advanced Intelligent DSP RF Receiver (72 MHz)(Listen Technologies Advanced Intelligent Dsp Rf Receiver 72 Mhz)

The Advanced Intelligent DSP RF Receiver from Listen Technologies is an advanced iDSP IR receiver. It features DSP SQ noise reduction technology, allowing users to experience 20 dB less noise and hiss. A field-replaceable, Lithium-ion battery is included with the unit. The integrated neck loop/lanyard with DSP loop driver improves the listening experience for T-coil users.

The unit has an OLED display to program channel names, monitor battery status, channel status, and charge activation. Programmable channel select summary allows user to cycle through active channels, seek to, or lock to a channel. Connect the iDSP neck loop/lanyard or ear phones via two 3.5mm output jacks (ear phones could be shared). The micro-USB connection is used with the included iDSP software for charging, set up, programming, inventory management, and firmware updates.

Listen Technologies Advanced Intelligent DSP RF Receiver (72 MHz)

Audio
Frequency Response	50 Hz to 15 kHz (�3 dB)
Signal to Noise Ratio	SQ enabled 80 dB, SQ disabled 60 dB
Distortion	<2% total harmonic distortion (THD) at 80% deviation
Audio Output Jacks	2 x 3.5 mm connectors, unbalanced, 0 dBu nominal output level, 16 mW maximum, impedance 32 ohm

Controls
User Controls	Power, up/down volume, Listen summary for end user channel selection
Set-Up	Press and hold up/down volume summarys for 5 seconds to enter channel adjust, use up/down to select channel
Programming	Via software and USB port

Indicators
Display	Channel designation, battery level, unit number, charging status
LEDs	Flashes when batteries are low or to indicate charging, solid when fully charged

RF Specification
Frequency Range	72.025 to 75.95 MHz
Number of Channels	17 wideband, 40 narrowband
Sensitivity	0.6 uV typical, 1 uV maximum for 12 dB sinad
Frequency Accuracy	� .005% stability 32 to 122�F (0 to 50�C)
Antenna Type	Uses ear phone/neck loop lanyard and short ear phone cable or standard earphone cable
Squelch	Programmable in 20 steps, automatic on loss of RF signal

Power
Battery Type	Lithium-ion 3.7 VDC, 1200 mAh
Battery Life	8 hours of continuous use
Battery Charging Time	Fully charged in 2.5 hours
Power Supply	Micro-USB connector, 5 V, 500 mA

Environmental
Operating Temperature	14 to 104�F (-10 to 40�C)
Storage Temperature	-4 to 122�F (-20 to 50�C)
Humidity (Non-condensing)	0 to 95% relative humidity

Compliance and Approvals
Standards	FCC Part 15, Part 90, Industry Canada, RoHS

Physical
Color	Flat black
Dimensions	Unit: 3.75 x 2 x 0.64″ (9.6 x 5 x 1.7 cm) Unit with Belt Clip: 3.75 x 2 x 0.80″ (9.6 x 5 x 2.1 cm)
Weight	Unit: 1.6 oz (45 g) Unit with Batteries: 2.4 oz (68 g)

Packaging Info
Package Weight	0.2 lb
Box Dimensions (LxWxH)	4.3 x 2.4 x 1.2″
