Bring easy visibility to industrial environments with the 15.6″ TK1560/C Specialty Monitor from Lilliput. Featuring a metal construction and IP64 dust and water resistance, this monitor is optimized for industrial applications. The 15.6″ LCD panel features 160° viewing angles, a 1000:1 static contrast ratio, and 1000 cd/m² of brightness for accurate views. Connect to video sources via HDMI, VGA, and RCA composite inputs; integrated speakers provide onboard audio, while a 3.5mm aux port can be used to connect headphones. VESA 75 x 75 and 100 x 100mm mounting patterns allow this monitor to be used with compatible third-party mounts or stands for versatile deployment.
In the Box
- Lilliput TK1560/C 15.6″ Full HD Specialty Monitor
- 12V 3A Power Adapter
- HDMI Cable
- VGA Cable
- Audio & Video Input Cables
- 4 x Screws
- 4 x Gaskets
- 4 x Cable Clamps
- Description
- Industrial-Grade Screen
- 15.6″ Display
- Ports Aplenty
- IP64 Dust and Water Resistance
- Secure Connectivity
Lilliput TK1560 Specs
| Screen Size (Diagonal) | 15.6″ |
| Resolution | 1920 x 1080 |
| Supported Display Resolutions | Maximum: 3840 x 2160 / 30 Hz |
| Panel Type | LCD |
| Brightness | 1000 cd/m² |
| Viewing Angle (H x V) | 160 x 160° |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1000:1 |
| Primary Connectivity Location | Display |
| Input Ports | 1 x HDMI 1.4 � Audio, Video (Bottom) 1 x VGA 15-Pin � Video (Bottom) 1 x RCA Composite � Video (Bottom) 1 x 1/8″ / 3.5 mm � Audio (Bottom) |
| Output Ports | 1 x 1/8″ / 3.5 mm � Headphone (Bottom) |
| Ethernet Ports | None |
| Bluetooth | None |
| Digital Media Slot | None |
| Built-In Speakers | Yes |
| Power Consumption | Maximum: < 24.5 W |
| DC Input Power | 12 to 24 VDC |
| Power Adapter Type | Internal |
| Operating Temperature | -4 to 140°F / -20 to 60°C |
| Storage Temperature | -22 to 158°F / -30 to 70°C |
| Wall Mounting | 75 x 75 mm 100 x 100 mm |
| Material of Construction | Metal |
| IP Rating | IP64 |
| Dimensions | 16.1 x 10.2 x 1.4″ / 408.0 x 259.0 x 36.5 mm |
| Weight | 6.4 lb / 2.9 kg |
| Package Weight | 8.765 lb |
| Box Dimensions (LxWxH) | 18.1 x 15.3 x 4.2″ |
