The LILLIPUT FA1011-NP/C/T 10.1″ Touchscreen LCD Monitor offers a native resolution and supports resolutions up to 1920 x 1080 via HDMI. It has 250 cd/m 2 brightness, 500:1 contrast ratio, and features a 4-wire resistive touch panel. It supports NTSC and PAL video signals. With a 16:9 wide screen, this monitor is suitable for a variety of A/V applications. It can be installed in TV broadcast rooms or as a preview monitor for professional cameras.
The monitor can be used with a computer, Blu-ray player, CCTV camera, or a DLSR camera via the HDMI, VGA, A/V, and DVI input ports. The monitor offers a clear, sharp picture, thanks to its high contrast ratio and LED backlight matte display that presents accurate colors and leaves no reflection on the screen. It comes with a built-in desktop stand that provides sturdy support for the monitor when set up on a desktop. It also features a VESA 75 mount when the desktop stand is detached, providing you with virtually unlimited mounting options.
- 10.1″ LCD monitor with 16:9 aspect ratio
- 4-wire resistive touch panel
- Native resolution of 1024 x 600 pixels
- Supports video inputs up to 1920 x 1080 through HDMI
- HDMI, VGA, AV, and DVI inputs
- 250 cd/m² brightness and 500:1 contrast ratio
- 140° / 110° (H / V) viewing angles
- Two mounting options-built-in desktop stand or standard VESA sockets (75mm)
| Display Screen | 10.1″ (25.7 cm) LED backlit |
| Resolution | 1024 x 600 Maximum: 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Color System | PAL-4.43, NTSC-3.58 |
| Touch Panel | 4-wire resistive |
| Contrast Ratio | 500:1 |
| Brightness | 250 cd/m² |
| Viewing Angle | 140° / 110° (H / V) |
| Input Signal | AV1, AV2, VGA, HDMI, DVI |
| Audio Output | ?1.2 W |
| Input Voltage | 12 VDC |
| Power Consumption | ?9 W |
| Mounting Options | Built-in desktop stand Standard VESA sockets (75 mm) |
| Dimensions (L x W x D) | 10.0 x 6.4 x 1.3″ (254.5 x 163.0 x 34.0 mm) without bracket 10.0 x 6.4 x 2.5″ (254.5 x 163.0 x 63.5 mm) with bracket |
| Weight | 2.478 lb (1.124 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 5.1 lb |
| Box Dimensions (LxWxH) | 12.9 x 11.3 x 3.6″ |
- Touch Pen
- 8-Key Remote Control
- HDMI to HDMI Cable
- HDMI to DVI Cable
- VGA Cable
- 14-Pin SKS Cable
- 12 VDC Adapter
- CD
- Limited 1-Year Warranty
