LG VL5PJ-A Overview
The LG VL5PJ-A 55″ Full HD Video Wall Monitor is a 500 nits bright IPS LCD display with ultraslim bezels, 24/7 operation capability, built-in system-on-chip and webOS smart signage platform, making it well suited for use in retail, corporate, hospitality, and other demanding applications. While the VL5PJ-A can be deployed as a single stand-alone display, it is designed to be combined with multiple units to create large video wall displays with a narrow 3.5mm bezel-to-bezel seam.
- Embedded CMS (Local Contents Scheduling, Group Manager)
- IP5X dust protection
- USB Plug & Play
- Fail Over
- RS-232 sync
- Setting data cloning
- SNMP
- ISM Method
- Crestron Connected 2 compatible
- HDMI CEC
- Pro:Idiom
Items Included
- LG VL5PJ-A 55″ Full HD Video Wall Monitor
- Remote Control with Batteries
- Power Cord
- RS-232C Cable
- DisplayPort Cable
- IR Receiver
- Guide Bracket
- Screws
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
LG VL5PJ-A Specs
| Display Size |
55″ |
| Native Resolution |
1920 x 1080 |
| Maximum Brightness |
500 nits / cd/m2 |
| Touchscreen |
No |
| Inputs |
2x HDMI 1x DVI-D 1x DisplayPort 1x 1/8″ / 3.5 mm (Analog Audio) |
| Outputs |
1x DisplayPort 1x 1/8″ / 3.5 mm (Analog Audio) |
| USB I/O |
1x USB-A (Unspecified Version) |
| Ethernet I/O |
1x RJ45 |
| Other I/O |
1x 1/8″ / 3.5 mm IR Input 1x DE-9/DB-9 Serial (RS-232C) Control Input 1x DE-9/DB-9 Serial (RS-232C) Control Output |
| Built-In Speakers |
No |
| Display Size |
55″ |
| Panel Type |
IPS-Type LCD |
| Aspect Ratio |
16:9 |
| Display Orientation |
Landscape, Portrait |
| Native Resolution |
1920 x 1080 |
| Maximum Brightness |
500 nits / cd/m2 |
| Lighting System |
Direct LED |
| HDR Support |
No |
| Contrast Ratio |
1200:1 |
| Dynamic Contrast Ratio |
500,000:1 |
| Response Time |
8 ms (GtG) |
| Refresh Rate |
60 Hz |
| Color Support |
1.07 Billion Colors (10-Bit) |
| Color Gamut |
72% NTSC |
| Viewing Angle (H x V) |
178 x 178° |
| Finish |
Anti-Glare / Matte |
| Touchscreen |
No |
| Haze Level |
3% |
| TV Tuner |
No |
| Inputs |
2x HDMI 1x DVI-D 1x DisplayPort 1x 1/8″ / 3.5 mm (Analog Audio) |
| Outputs |
1x DisplayPort 1x 1/8″ / 3.5 mm (Analog Audio) |
| HDCP Support |
Yes, Version 1.4/2.2 |
| USB I/O |
1x USB-A (Unspecified Version) |
| Ethernet I/O |
1x RJ45 |
| Other I/O |
1x 1/8″ / 3.5 mm IR Input 1x DE-9/DB-9 Serial (RS-232C) Control Input 1x DE-9/DB-9 Serial (RS-232C) Control Output |
| Multi-Input Support (PIP/PBP) |
No |
| Built-In Speakers |
No |
| Smart TV |
Yes, webOS 4.1 |
| Storage |
8 GB eMMC |
| Built-In Mic |
No |
| Power Consumption |
Typical: 135.0 W Maximum: 150.0 W Eco Mode: 80.0 W Standby: < 0.5 W |
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type |
Internal |
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 80% Humidity |
| Certifications |
CB, CE, ENERGY STAR 8.0, FCC Class A, NRTL |
| VESA Mounting-Hole Pattern |
600 x 400 mm |
| Lighting Lifespan |
60000 Hours |
| Environmental Resistance |
Dust-Resistant (IP5X) |
| Impact Resistance |
No |
| Bezel Thickness |
2.25 mm (Top/Left) 1.25 mm (Bottom/Right) |
| Duty Cycle |
24 Hours / 7 Days |
| Dimensions |
47.8 x 26.9 x 3.7″ / 1213.4 x 684.2 x 93.1 mm |
| Weight |
51.8 lb / 23.5 kg |
| Package Weight |
58.5 lb |
| Box Dimensions (LxWxH) |
53.06 x 33.25 x 10.38″ |
