LG UH5N-E Overview
The LG 43UH5N-E 43″ UHD 4K Commercial Monitor is a 500 nits bright digital signage display featuring the convenient LG webOS SoC and advanced security features. This durable IP5X-certified display provides 24/7 reliability in a space-saving design, perfect for demanding retail and corporate environments. Connect sources via HDMI and DisplayPort inputs, or load content using a USB flash drive or the embedded webOS platform.
- USB plug and play
- Fail over
- Logo image on boot
- RS-232 and LAN sync
- Picture-in-picture, picture-by-picture (up to 4 inputs)
- Play via URL
- Screen rotation / external input rotation
- Gapless playback
- Tile mode up to 15 x 15
- USB settings data cloning
- SNMP and ISM method
- Cisco amd Crestron Inside certified
- Beacon
- HDMI-CEC
- SI server setting
- webRTC
- Pro:Idiom
In the Box
- LG 43UH5N-E 43″ UHD 4K Commercial Monitor
- Power Cord
- Remote Control
- 2 x AAA Battery for Remote
- 2 x Cable Management Clip
- RS-232 Adapter
- Limited 3-Year Manufacturer Warranty
Additional Resources
User Manual
2.6 MB
LG UH5N-ESpecs
| Display Size |
43″ |
| Native Resolution |
3840 x 2160 |
| Maximum Brightness |
500 nits / cd/m2 |
| Inputs |
3x HDMI 1x DisplayPort |
| Outputs |
1x HDMI 1x 1/8″ / 3.5 mm (Analog Audio) |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth |
| USB I/O |
1x USB-A 2.0 |
| Ethernet I/O |
1x RJ45 (Unspecified Ethernet) |
| Other I/O |
1x 1/8″ / 3.5 mm Serial (RS-232C) Control Input 1x 1/8″ / 3.5 mm Serial (RS-232C) Control Output 1x 1/8″ / 3.5 mm IR / Ambient Sensor Input |
| Built-In Speakers |
Yes |
| Media Card Reader |
No |
| Display Size |
43″ |
| Panel Type |
IPS-Type LCD |
| Aspect Ratio |
16:9 |
| Display Orientation |
30° Downward Angle, Landscape, Portrait |
| Native Resolution |
3840 x 2160 |
| Maximum Brightness |
500 nits / cd/m2 |
| Lighting System |
Edge-Lit LED |
| Contrast Ratio |
1000:1 |
| Dynamic Contrast Ratio |
1,000,000:1 |
| Response Time |
< 10 ms |
| Refresh Rate |
60 Hz |
| Color Support |
1.07 Billion Colors (10-Bit) |
| Color Gamut |
95% Rec. 709 |
| Viewing Angle (H x V) |
178 x 178° |
| Horizontal Frequency |
28.1 to 135 kHz |
| Vertical Frequency |
30 to 60.317 Hz |
| Pixels Per Inch (ppi) |
51 ppi |
| Finish |
Anti-Glare / Matte |
| Haze Level |
28% |
| TV Tuner |
No |
| Inputs |
3x HDMI 1x DisplayPort |
| Outputs |
1x HDMI 1x 1/8″ / 3.5 mm (Analog Audio) |
| HDCP Support |
Yes, Version 2.2 |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth |
| USB I/O |
1x USB-A 2.0 |
| Ethernet I/O |
1x RJ45 (Unspecified Ethernet) |
| Other I/O |
1x 1/8″ / 3.5 mm Serial (RS-232C) Control Input 1x 1/8″ / 3.5 mm Serial (RS-232C) Control Output 1x 1/8″ / 3.5 mm IR / Ambient Sensor Input |
| Ambient Light Sensor |
Yes |
| Multi-Input Support (PIP/PBP) |
Picture-in-Picture (PIP), Picture-by-Picture (PBP) |
| Built-In Speakers |
Yes |
| Smart TV |
webOS 6 |
| Storage |
16 GB |
| OS Compatibility |
Android/iOS |
| Mobile App Compatible |
Yes: Android & iOS |
| Media Card Reader |
No |
| Built-In Mic |
No |
| Supported Languages |
Arabic Czech Danish Dutch English Finnish French German Greek Italian Japanese Korean Norwegian Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish |
| Power Consumption |
Maximum: 120.0 W Typical: 80.0 W Eco Mode: 56.0 W Standby: < 0.5 W |
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type |
Internal |
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 80% Humidity |
| Storage Conditions |
-4 to 140°F / -20 to 60°C at 5 to 85% Humidity |
| Certifications |
CB, NRTL, FCC Class “B”, CE, KC, ErP, ENERGY STAR, EPEAT |
| Mounting-Hole Pattern |
200 x 200 mm |
| Lighting Lifespan |
50000 Hours |
| Lock Slot |
Yes, Kensington |
| Bezel Thickness |
8.9 mm (Right/Top/Left) 12.9 mm (Bottom) |
| Duty Cycle |
24 Hours / 7 Days |
| Dimensions |
37.9 x 21.9 x 1.2″ / 963 x 556.2 x 29.7 mm |
| Weight |
24.5 lb / 11.1 kg |
