HPE Networking JL686B#ABA Overview
The HPE Networking Instant On 1930 48-Port PoE+ Compliant Managed Network Switch helps to quickly grow your small business’s network capacity to operate power over Ethernet devices such as IP security cameras, access points, and VoIP phones. This entry-level managed rackmount switch includes 48 Gigabit PoE+ compliant Ethernet ports, each capable of providing 30W of power with a budget of 370W. Four Gigabit SFP+ ports are available for 10Gb fiber uplink connections. Use the HPE Networking Instant On mobile app, cloud-based web portal, or local web interface to quickly configure, manage, and monitor the HPE Networking Instant On 1930 network switch.
Automatic denial-of-service (DoS) monitors and protects the network against malicious attacks.
Management security restricts access to critical configuration commands and offers multiple privilege levels with password protection.
Items Included
- HPE Networking Instant On 1930 48-Port PoE+ Compliant Managed Network Switch with SFP+ (370W)
- Power Cable
- Limited Lifetime Warranty
Additional Resources
User Manual
0.3 MB
More from manufacturer
HPE Networking JL686B#ABA Specs
| Inputs/Outputs |
48x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at) 4x SFP+ 10 GbE WAN |
| Stackable |
No |
| Switching Bandwidth |
176 Gb/s |
| PoE Power Budget |
370 W |
| Stackable |
No |
| Security Features |
DoS Attack Prevention |
| Forwarding Rate |
130.95 Mpps |
| Switching Bandwidth |
176 Gb/s |
| Packet Buffer |
1.5 MB |
| Flash Memory |
256 MB |
| CPU |
Single-Core: Up to 800 MHz Cortex A9 |
| Memory |
512 MB |
| PoE per Port |
30 W |
| PoE Power Budget |
370 W |
| Power Draw |
520.00 W (Max) 50.00 W (Idle) |
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Supply Type |
Internal |
| Certifications |
No |
| Indicator Lights |
Yes |
| Rack Mountable |
Yes 1 RU |
| Dimensions |
17.42 x 12.7 x 1.73″ / 44.25 x 32.26 x 4.39 cm |
| Weight |
10.12 lb / 4.59 kg |
| Package Weight |
14.14 lb |
| Box Dimensions (LxWxH) |
19.5 x 17.5 x 4″ |
