Hikvision DS-KD8003-IME1 Video Intercom Module Door Station With Surface Mount(Hikvision Ds Kd8003 Ime1 Video Intercom Module Door Station With Surface Mount)

Original price was: $324.00.Current price is: $97.99.

SKU: DGFUB 4309395439701 Categories: Intercoms, Optics & Surveillance, Surviellance Tags: Door Stations, Intercoms, Surveillance

Elevate Your Shopping Experience
Product guarantee 100% satisfaction
The quality solution for all your needs.
Streamlined service, designed for your convenience.

Description
Reviews (0)

Hikvision DS-KD8003-IME1/SURFACE Overview

The DS-KD8003-IME1 Video Intercom Module Door Station with Surface Mount from Hikvision combines video intercom and access control functionality in one unit. It has a built-in omnidirectional microphone and speaker with noise suppression and echo cancellation for two-way audio. An integrated fisheye camera equipped with a CMOS sensor captures 1920 x 1080 resolution video from a 180° horizontal field of view. An IR supplement provides illumination for low-light conditions.

This device is IP65 rated when mounted.

Provides video intercom and access control functionality

Embedded MCU processor and Linux OS

Simple operation via physical summary

Integrated 2MP fisheye camera

IR supplement for low-light illumination

Image enhancements include backlight compensation, digital noise reduction, and wide dynamic range

Noise suppression and echo cancellation for clear sound

H.264 video compression

100M self-adaptive Ethernet

Tampering alarm

Name tag customization

Supports sub-module access (eight maximum)

ONVIF compliant

FCC, CE, and cUL certified

UPC: 842571125979

In the Box

Hikvision DS-KD8003-IME1 Video Intercom Module Door Station with Surface Mount

Surface Mount

Limited 3-Year Warranty

Hikvision DS-KD8003-IME1/SURFACE Specs

System

Processor	Embedded MCU
Operating System	Embedded Linux
Operation Method	Physical Button

Video

Image Sensor	2 MP CMOS Sensor
Video Compression	H.264
Resolution	Main Stream: 1920 x 1080 Sub Stream: 720 x 480
Image Enhancement	BLC, DNR, WDR
Anti-Flicker	50/60 Hz
Field of View	Horizontal: 180° Vertical: 96°

Audio

Audio Input	Built-In Omnidirectional Microphone
Audio Output	Built-In Omnidirectional Loudspeaker (>85 dB within 7.9″ / 20 cm)
Compression	G.711 U
Compression Rate	64 kb/s
Audio Quality	Noise Suppression and Echo Cancellation

IR Illuminator

IR Illumination

IR Supplement

Network

Ethernet	100M Self-Adaptive Ethernet
Network Protocols	TCP/IP, RTSP

Alarm

Tamper Alarm

Interfaces

Connectors

1 x Module
4 x I/O
1 x Debug
2 x Relay(30 V, 1 A)

General

Power Supply	12 VDC, PoE IEEE 802.3af
Power Consumption	?10 W
Operating Temperature	-40 to 140°F / -40 to 60°C
Operating Humidity	10 to 95% Non-Condensing
IP Rating	IP65 (When Mounted in Enclosure)
Certifications	FCC, CE, cUL
Dimensions	4.21 x 4.61 x 1.81″ / 107 x 117 x 46 mm

Packaging Info

Package Weight	1.81 lb
Box Dimensions (LxWxH)	6.8 x 6.8 x 4.6″
