Elo Touch 1715L Overview
The Elo Touch 1715L E719160 IntelliTouch 17″ SXGA Touchscreen Commercial Monitor is a compact and durable display, with single-point touch interactivity for professional applications, like point-of-sale or information services. The 1715L includes a desktop stand with tilting capability, side controls, and lock-out capability for public use. For added reliability in commercial environments the anti-glare touchscreen is sealed from dirt, dust, and liquid.
- Sealed touchscreen against dirt, dust, and liquids
- Mounting holes on stand bottom for tabletop security
- Long-lasting product cycle
- Digital on-screen display (OSD)
Items Included
- Elo Touch 1715L E719160 IntelliTouch 17″ SXGA Touchscreen Commercial Monitor
- Power Cable
- VGA Cable
- USB Touch Cable
- Tabletop Stand
- 3 x Cable Tie Wrap
- Limited 3-Year Manufacturer Warranty
Additional Resources
User Manual
1.4 MB
Elo Touch 1715L Specs
| Display Size |
17″ |
| Native Resolution |
1280 x 1024 |
| Maximum Brightness |
225 nits / cd/m2 |
| Touchscreen Technology |
Resistive |
| Inputs |
1x DE-15/DB-15 (VGA) |
| Outputs |
No |
| Wireless |
No |
| USB I/O |
1x USB-B (Unspecified Version) (Touchscreen Control) |
| Ethernet I/O |
No |
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control / Touchscreen Input |
| Built-In Speakers |
No |
| Media Card Reader |
No |
| Display Size |
17″ |
| Panel Type |
TFT LCD |
| Aspect Ratio |
5:4 |
| Display Orientation |
Landscape |
| Native Resolution |
1280 x 1024 |
| Maximum Brightness |
225 nits / cd/m2 |
| Lighting System |
Direct LED |
| HDR Support |
No |
| Contrast Ratio |
1000:1 |
| Response Time |
20 ms |
| Refresh Rate |
60 Hz |
| Color Support |
16.7 Million Colors |
| Viewing Angle (H x V) |
170 x 160° |
| Screen Area |
13.3 x 10.6″ / 338 x 270 mm |
| Horizontal Frequency |
31.5 to 80 kHz |
| Vertical Frequency |
56.3 to 75 Hz |
| Pixels Per Inch (ppi) |
96 ppi |
| Finish |
Anti-Glare / Matte |
| Touchscreen Technology |
Resistive |
| Multi-Touch Points |
1 |
| TV Tuner |
No |
| Inputs |
1x DE-15/DB-15 (VGA) |
| Outputs |
No |
| HDCP Support |
No |
| Wireless |
No |
| NFC |
No |
| USB I/O |
1x USB-B (Unspecified Version) (Touchscreen Control) |
| Ethernet I/O |
No |
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control / Touchscreen Input |
| Multi-Input Support (PIP/PBP) |
No |
| Built-In Speakers |
No |
| Mobile App Compatible |
No |
| Media Card Reader |
No |
| Built-In Mic |
No |
| Supported Languages |
English French German Italian Japanese Simplified Chinese Spanish Traditional Chinese |
| Power Consumption |
Typical: 10.5 W Standby: 1.3 W |
| Input Power |
12 VDC 100 to 240 VAC, 50 / 60 Hz |
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 80% Humidity |
| Storage Conditions |
-4 to 140°F / -20 to 60°C at 10 to 95% Humidity |
| Certifications |
cUL, IC, CCC, CE, UKCA, Kcc, BSMI, FCC, UL, VCCI, CB, RCM, EAC, NOM, RoHS, WEEE, REACH |
| Mounting-Hole Pattern |
100 x 100 mm |
| Lighting Lifespan |
50000 Hours |
| Dimensions |
15.4 x 14.4 x 8″ / 391 x 366 x 203 mm (with Stand) 15.4 x 13 x 2.4″ / 391 x 331 x 62 mm (without Stand) |
| Weight |
15.2 lb / 6.9 kg |
