Elo Touch 1517L E829550 IntelliTouch ZB 15" XGA Touchscreen Commercial Monitor(Elo Touch 1517l E829550 Intellitouch Zb 15 Xga Touchscreen Commercial Monitor)

Elo Touch 1517L E829550 IntelliTouch ZB 15″ XGA Touchscreen Commercial Monitor(Elo Touch 1517l E829550 Intellitouch Zb 15 Xga Touchscreen Commercial Monitor)

Original price was: $357.00.Current price is: $99.99.

SKU: DGFUB 7074872459349 Categories: Audio Visual Presentation, Computer & Presentation Tags: All Commercial Monitors, Audio Visual Presentation, Commercial Monitors & Displays, Elo Touch 1517L

Elevate Your Shopping Experience
Product guarantee 100% satisfaction
The quality solution for all your needs.
Streamlined service, designed for your convenience.

Description
Reviews (0)

Elo Touch 1517L Overview

The Elo Touch 1517L E829550 IntelliTouch ZB 15″ XGA Touchscreen Commercial Monitor is a 270 nits bright, single-point touch display, with a sleek zero-bezel design, and retail focused features, that is well suited for applications like point-of-sale, information services, and interactive signage. Sources can be connected via HDMI or VGA, with USB or RS-232 for touch control. Additionally, this monitor can be powered by the included AC power cable, or with a separately available DC power adapter.

Integrated Touch

The IntelliTouch surface acoustic wave (SAW) zero-bezel offers stable, drift-free dual-touch functionality, and delivers the ultimate in optical quality for dry retail and hospitality applications.

MSR Ready

The optional ergonomic three-track mag stripe reader (MSR) is easily installed providing an elegant, integrated solution. The MSR is available in two versions, USB with keyboard emulation, and USB with human interface device (HID).

Installation Flexibility

The Elo 1517L offers multiple mounting options to ensure installation flexibility, including wall and pole-mount via 75 x 75mm VESA mount as well as tabletop with the use of the included stand. Additionally, capped through-mount holes on the base of the monitor ensure table-top security.

Additional Features

Dual serial/USB touch interface
Screen is sealed against dirt, dust, and liquid
Power via internal AC power or optional external 12VDC power supply

Items Included

Elo Touch 1517L E829550 IntelliTouch ZB 15″ XGA Touchscreen Commercial Monitor
Power Cable
HDMI Cable
VGA Cable
USB Touch Cable
Stand Base Assembly
Filler Plate
Limited 3-Year Manufacturer Warranty

Additional Resources

User Manual

1.0 MB

Elo Touch 1517L Specs

Key Specs

Display Size	15″
Native Resolution	1024 x 768
Maximum Brightness	270 nits / cd/m²
Touchscreen Technology	Resistive
Inputs	1x HDMI 1x DE-15/DB-15 (VGA)
Outputs	No
Wireless	No
USB I/O	1x USB-B (Unspecified Version) (Touchscreen Control)
Ethernet I/O	No
Other I/O	1x DE-9/DB-9 Serial (RS-232C) Control Input
Built-In Speakers	No
Media Card Reader	No

Display

Display Size	15″
Panel Type	TFT LCD
Aspect Ratio	4:3
Display Orientation	Landscape
Native Resolution	1024 x 768
Maximum Brightness	270 nits / cd/m²
HDR Support	No
Contrast Ratio	800:1
Response Time	23 ms
Color Support	16.2 Million Colors (6-Bit+FRC)
Viewing Angle (H x V)	160 x 150°
Screen Area	11.97 x 8.98″ / 304.13 x 228.10 mm
Horizontal Frequency	31.5 to 60 kHz
Vertical Frequency	56 to 75 Hz
Pixels Per Inch (ppi)	85 ppi
Finish	Glossy

Surface

Touchscreen Technology	Resistive
Multi-Touch Points	1

Video

TV Tuner

Connectivity

Inputs	1x HDMI 1x DE-15/DB-15 (VGA)
Outputs	No
Wireless	No
NFC	No
USB I/O	1x USB-B (Unspecified Version) (Touchscreen Control)
Ethernet I/O	No
Other I/O	1x DE-9/DB-9 Serial (RS-232C) Control Input
Ambient Light Sensor	No
Multi-Input Support (PIP/PBP)	No
Built-In Speakers	No

Hardware

Mobile App Compatible	No
Media Card Reader	No
Built-In Mic	No
Supported Languages	English French German Italian Japanese Simplified Chinese Spanish Traditional Chinese

Electrical

Power Consumption	Operational: 10.5 W Standby: 1.4 W
Input Power	12 VDC 100 to 240 VAC, 50 / 60 Hz

General

Operating Conditions	32 to 104°F / 0 to 40°C at 20 to 80% Humidity
Storage Conditions	-4 to 140°F / -20 to 60°C at 10 to 95% Humidity
Certifications	cUL, IC, CCC, CE, UKCA, Kcc, BSMI, FCC, VCCI, CB, RCM, EAC, NOM, BIS, RoHS, WEEE
Mounting-Hole Pattern	75 x 75 mm
Lighting Lifespan	50000 Hours
Dimensions	14.1 x 12.6 x 7.8″ / 358 x 319 x 197 mm (with Stand) 14.1 x 12.6 x 2″ / 357 x 319 x 50 mm (without Stand)
Weight	16.1 lb / 7.3 kg (with Stand)
