Dsan PC-433-MINI-AS4GRN Overview
The PerfectCue Mini with 4-Button Transmitter and Green Laser Pointer from DSAN is a cue light system that provides a compact signaling solution allowing a presenter to send cues to the technical presentation manager via a handheld wireless transmitter from up to 300′ away. The system includes a four-summary transmitter with three command summarys and a fourth summary that controls a green laser pointer.
Press the control summarys on the remote for forward, back, start, or stop, and the lights on the receiver will illuminate to cue the presentation tech. When the receiver is connected to a computer via a USB port, additional software can be configured to create the keystrokes for changing slides or cues in your presentation or lighting software. Sound cues can also be configured and heard via headphones.
Integrated into the signaling system are RJ45 and XLR jacks that can connect multiple cue lights for numerous presentation control options. One transmitter can control multiple cue lights.
Items Included
- Dsan PerfectCue Mini with 4-Button Transmitter and Green Laser Pointer
- 4-Button Transmitter
- 12 VAC Power Adapter
- 2 x USB Cable
- Padded Carry Case
- Limited 1-Year Manufacturer Warranty
Additional Resources
No additional resources available
Dsan PC-433-MINI-AS4GRN Specs
| Input/Output Connectors |
1 x RJ45 1 x XLR 1 x Barrel Power 2 x USB |
| Laser Power |
<3 mW, 530 nM |
| Wireless Protocols |
RF |
| RF Range |
300′ / 100 m |
| Power |
Transmitter: 2 x CR2032 Batteries and 1 x CR123 Battery Receiver: 12 VAC |
| Dimensions |
Transmitter: 3.5 x 1.9 x 0.8″ / 8.9 x 4.8 x 2 cm Transmitter Antenna Length: 1.3″ / 3.3 cm Receiver: 5.7 x 1.1 x 3″ / 14.5 x 2.8 x 7.6 cm |
| Weight |
Transmitter: 2.5 oz / 71 g Receiver: Not Supplied by Manufacturer |
| Package Weight |
7.45 lb |
| Box Dimensions (LxWxH) |
14.6 x 12.1 x 5.4″ |
