Dotworkz D2 Heater Blower Enclosure With Multi Volt Platform(Dotworkz D2 Heater Blower Enclosure With Multi Volt Platform)

The Dotworkz D2 Heater Blower Enclosure with MVP is constructed of a rugged polycarbonate thermal plastic alloy material and uses a built-in heater and blower system to shield the camera from the cold and to keep the viewing window from fogging up in humid conditions. The heater is thermostatically controlled while the blower operates continuously. In addition to its internal climate control system, this housing is IP66 rated against dust, water, and salt water air ingress and features IP68 rated connection ports.

This housing can be powered from a 24VAC, 110VAC or 220VAC power source. It also has internal 12VDC and 24VAC outputs to power an IP or analog camera.

This housing is compatible with most analog or IP PTZ dome cameras and has extra room to accommodate peripherals such as encoders, hard drives, routers, etc. A switchable internal mounting mechanism allows top and bottom camera placement for versatile camera positioning and for maximizing internal space. The lower dome is impact resistant and at the same time is optically clear to ensure maximum image sharpness.

Mount Type	Wall mount (optional corner, pole brackets available)
Compatible Cameras	Analog or IP PTZ camera
Clear or Tinted	Clear
Construction	Housing: Dotworkz thermoplastic alloy Bubble: Precision view high impact acrylic
Enclosure Rating	IP66 with IP68 connection ports
Operating Temperature	Absolute: -25 ~ +140°F (-32 ~ +60°C) Recommended: 0 ~ 120°F (-17 ~ +49°C)
Power Input	24VAC, 110VAC, or 220VAC
Power Output	(to camera) IP: 12VDC, 24VDC AC (CCTV): 12VDC, 24VAC
Power Consumption	2 amps @ 115VAC typical at full load
Dimensions (WxHxD)	11.7 x 13.4 x 14.9″ (297 x 340 x 378mm)

Packaging Info
Package Weight	12.85 lb
Box Dimensions (LxWxH)	17.2 x 15.9 x 13.0″

Dotworkz D2 Heater Blower Enclosure with Multi Volt Platform
