DayStar Filters Eclipse Orchestrator Pro 3.7 Camera Control Software (Boxed CD)(Daystar Filters Eclipse Orchestrator Pro 3 7 Camera Control Software Boxed Cd)

• Allows you to pre-program exposures, indicating when you would like each one to occur and which settings you would like selected for each
• Set shutter speed, ISO, aperture, file type, and quality
• Scripted shutter press control available via serial port cable
• All actions of the camera can be timed to line up with specific phases of the event you’re observing
• Software sends commands to camera through USB to select settings and capture images, which are saved to camera’s memory card
• All features of Orchestrator Pro are optional, so you can use the program for as much or as little as you like
• Benefit from script editing and customization
• Scriptable command lines
• Intervalometer function, including “ending at” time, can also be scripted
• Scripted playback of self-recorded .wav sound files
• Upcoming script event display
• Support for “emergency” script, which can be executed easily to adapt to cloud openings

• Enter latitude and longitude coordinates or connect an NMEA 0183-compatible GPS, in order to enable the software to determine your precise location (within about 200 m), time (within about 0.5 sec), and other circumstances/conditions
• Features satellite terrain map, umbral path (the path of the Moon’s inner shadow across Earth’s surface), and zones of longest duration
• Animated umbral shadow with mouse-over duration info
• Map, simulated view, and countdown in separate windows that can be resized
• Main display screen can be customized
• Local circumstances table
• Refraction, limb effects, and delta-T correction are supported
• With limb and refraction corrections enabled, and precise GPS coordinates and GPS time set at your observation site, contact time predictions should be accurate to within +/- 2 sec
• Using UTC event times also allows for extreme accuracy
• Predictions for previous eclipses were usually within 1 sec
• “Simulated second contact” option
• Manual entry or override of computed contact times if necessary
• Easy adjustment of computer clock without GPS

• Neilsen-Kellerman Kestrel 4000 weather tracker support, allowing for scheduled memory downloads with required Kestrel Interface
• “View Exposure Sequence” option
• “View Log” option
• Live View window with focus metric for Canon DSLRs
• Capture single exposure via settings dialog
• Mirror lock-up support to reduce vibration
• Camera “nicknaming” ID feature

• Using a USB or Firewire cable, connect your camera to a laptop running Microsoft Windows XP, Vista, 7, 8, or 10
• Support for up to 16 cameras at once
• High-speed shooting is possible with serial ports and optional serial-to-camera shutter cables, which can save 2-5 seconds’ worth of delay time. Typical speeds with cables range from 2-8 fps
• Software supports powered, non-powered, inverted, and Nikon IR shutter cables
• Serial RTS, DTR, and dual cables, as well as USB-to-serial converters, are supported. Multiple converters can be used via USB hub
• Purchase includes all minor upgrades and updates (3.xx)
• Customer support provided via website and email

• Canon EOS:
• 1D
• 1D Mark II
• 1D Mark III
• 1D Mark IV
• 1D X
• 1D X Mark II
• 1D C
• 1Ds
• 1Ds Mark II
• 1Ds Mark III
• 5D
• 5D Mark II
• 5D Mark III
• 5D Mark IV
• 5DS
• 5DS R
• 6D
• 7D
• 7D Mark II
• 10D
• 20D
• 20Da
• 30D
• 40D
• 50D
• 60D
• 60Da
• 70D
• 80D
• Digital Rebel/300D
• Rebel XT/350D
• Rebel XTi/400D
• Rebel XSi/450D
• Rebel XS/1000D
• Rebel T1i/500D
• Rebel T2i/550D
• Rebel T3/1100D
• Rebel T3i/600D
• Rebel T4i/650D
• Rebel T5/1200D
• Rebel T5i/700D
• Rebel T6/1300D
• Rebel T6i
• Rebel T6s/760D
• Rebel SL1/100D

Digital cameras not on this list are not supported
Following cameras not compatible with Windows Vista or 7, due to instability or lack of Canon driver: 1D, 1D Mark II, 1D Mark II N, 1Ds, 1Ds Mark II, 10D, 20D, 20Da, and Digital Rebel
Menu option “Setup/ Support Old Canons” must be checked to use one of these cameras on Windows XP: 1D, 1Ds, 10D, and Digital Rebel

• Nikon:
• D3
• D3X
• D3S
• D4
• D4S
• D5
• D40
• D40X
• D60
• D80
• D90
• D200
• D300
• D300s
• D500
• D600
• D610
• D700
• D750
• D800
• D800E
• D810
• D810A
• D7000
• D7100
• D7200
• D7500

Cameras must be set for PTP or MTP, not Mass Storage
Following cameras are not supported: D1, D1H, D1X, D100, D2H, D2Hs, D2X, D2Xs, D50, D70, D70s, D3000, D3100, D3200, D3300, D3400, D5000, D5100, D5200, D5300, D5500, D5600

Software can be used with film cameras via shutter operator (not included)
