Dahua Technology DH-DB6I Overview
Monitor your front door from anywhere you have internet access with the DH-DB6I 5MP Wi-Fi Video Doorbell from Dahua Technology. This IP65-rated Wi-Fi doorbell captures 2560 x 1920 resolution video at 15 fps. It features an IR illumination range up to 16.5′, a 2.2mm fixed lens that delivers a 124° horizontal field of view, motion detection with human detection functionality, and a built-in microphone and speaker for two-way audio.
Remote viewing and communication with visitors from your iOS or Android device is possible via the Dahua DMSS app. A built-in memory card slot supports microSD cards up to 256GB (32GB preinstalled).
In the Box
- Dahua Technology DH-DB6I 5MP Wi-Fi Video Doorbell
- Chime Kit
- Preinstalled 32GB microSD Card
- Wiring Package
- 15° Horizontal Bracket
- 5° Vertical Bracket
- Mounting Kit
Dahua Technology DH-DB6I Specs
| Resolution and Frame Rate | 2560 x 1920 at up to 15 fps |
| Field of View | 124° (Horizontal) 92° (Vertical) 164° (Diagonal) |
| Sensor | 1/2.7″ CMOS |
| Sensor Resolution | 5 MP |
| Aperture (Single Value) | f/2 |
| Focal Length | 2.2mm |
| Night Vision | Yes |
| Motion Sensor | Up to 16.40′ / 5 m |
| Memory Card Capacity Supported | 256 GB microSD |
| Supported Video Codecs | H.264, H.265 |
| Display | None |
| Wi-Fi | Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz) |
| Bluetooth | None |
| Intercom | Yes |
| Microphone Enhancements | None |
| Power Type Requirement | Hardwired |
| Power Requirements | 16 to 24 VAC |
| Power Consumption | 4.9 W |
| DC Input Power | 12 / 24 VDC |
| Operating Temperature | -4 to 122°F / -20 to 50°C |
| Operating Humidity | 0 to 95% |
| Material of Construction | Plastic |
| Certifications | FCC *as per Manufacturer |
| LED Indicators | Yes |
| IP Rating | IP65 |
| IK Rating | None |
| Dimensions | 5.1 x 1.8 x 0.9″ / 130 x 45 x 22.5 mm |
| Weight | 0.24 lb / 0.11 kg |
| Package Weight | 1.15 lb |
| Box Dimensions (LxWxH) | 7.6 x 7.3 x 2.1″ |
