Avocor AVK-8510 Overview
The Avocor K Series 85″ UHD 4K HDR QLED Commercial Monitor is a 450-nit bright, high-contrast QLED display with HDR local dimming to deliver high-quality visual presentations in corporate, education, and government applications.
The AVK-8510 features advanced capabilities like digital signage support via Rise Vision, and wireless screen sharing through Montage. Connect sources via HDMI and USB-C inputs, and deliver content over LAN or Wi-Fi using the embedded Android OS. The K Series is designed with energy efficiency in mind to help your organization meet sustainability goals while providing a dependable non-interactive display solution.
- Streamlined communication with UcaaS integration for seamless content delivery
- 90% DCI-P3 color space coverage
- Montage: Wireless sharing for any device
- Rise Vision: Customizable digital signage
- Built-in dual 10-watt speakers
Items Included
- Avocor K Series 85″ UHD 4K HDR QLED Commercial Monitor
- Power Cord
- Tabletop Stand
- Remote Control with Batteries
- Wall Mount Bracket
- Limited 3-Year Manufacturer Warranty
Additional Resources
User Manual
1.2 MB
Avocor AVK-8510 Specs
| Display Size |
85″ |
| Native Resolution |
3840 x 2160 |
| Maximum Brightness |
450 nits / cd/m2 |
| Touchscreen |
No |
| Inputs |
2x HDMI 2.1 |
| Outputs |
1x 1/8″ / 3.5 mm (Analog Audio) |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.0 |
| USB I/O |
1x USB-C (Unspecified Version) (Photo/Audio/Charging/Video) 1x USB-A 3.0 / 3.1/3.2 Gen 1 1x USB-B 2.0 |
| Ethernet I/O |
1x RJ45 |
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control Input |
| Built-In Speakers |
Yes, 2x 10 W |
| Display Size |
85″ |
| Panel Type |
Quantum Dot LCD (QLED) |
| Aspect Ratio |
16:9 |
| Display Orientation |
Landscape |
| Native Resolution |
3840 x 2160 |
| Maximum Brightness |
450 nits / cd/m2 |
| Lighting System |
Direct LED |
| HDR Support |
Yes |
| Contrast Ratio |
1200:1 |
| Response Time |
< 7 ms |
| Refresh Rate |
60 Hz |
| Color Support |
1.07 Billion Colors (10-Bit) |
| Color Gamut |
90% DCI-P3 |
| Viewing Angle (H x V) |
178 x 178° |
| Finish |
Anti-Glare / Matte |
| Touchscreen |
No |
| TV Tuner |
No |
| Inputs |
2x HDMI 2.1 |
| Outputs |
1x 1/8″ / 3.5 mm (Analog Audio) |
| HDCP Support |
Yes |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.0 |
| NFC |
No |
| USB I/O |
1x USB-C (Unspecified Version) (Photo/Audio/Charging/Video) 1x USB-A 3.0 / 3.1/3.2 Gen 1 1x USB-B 2.0 |
| Ethernet I/O |
1x RJ45 |
| Other I/O |
1x DE-9/DB-9 Serial (RS-232C) Control Input |
| Multi-Input Support (PIP/PBP) |
No |
| Built-In Speakers |
Yes, 2x 10 W |
| Speaker Configuration |
2-Channel |
| Smart TV |
Yes, Android 14 |
| Storage |
32 GB |
| RAM |
4 GB |
| Built-In Mic |
No |
| Power Consumption |
Maximum: 340.0 W |
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type |
Internal |
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 90% Humidity |
| Storage Conditions |
-4 to 140°F / -20 to 60°C at 10 to 90% Humidity |
| VESA Mounting-Hole Pattern |
500 x 200 mm |
| Impact Resistance |
No |
| Bezel Thickness |
3.5 mm (Right/Top/Left) 20.4 mm (Bottom) |
| Duty Cycle |
16 Hours / 7 Days |
| Dimensions |
74.6 x 43.2 x 4″ / 1894 x 1097 x 101 mm |
| Weight |
85.1 lb / 38.6 kg |
