Armasight Jockey 320 Overview

Jockey 320 19mm

The Jockey / Armasight USA

The Jockey 320 Compact Thermal Clip-On from Armasight mounts in front of any 1-6x daytime riflescope and enables it to be used as a night vision device. Its 320 x 240 thermal detector can detect human-sized heat signatures up to 774 yards away, displaying imagery on a 1024 x 768 OLED monitor and capturing video and photos. Suitable for AR platform or rimfire rfiles, airguns, and crossbows, the Jockey offers multiple color palettes, simple three-summary control, and four hours of runtime on two CR123A batteries. It comes with a quick-detach mount for your rifle’s rail.

Note:

Export of this device described herein is strictly prohibited without a valid export license issued by the U.S. Department of State Directorate of Defense Trade Controls, as prescribed in the International Traffic in Arms Regulations (ITAR), Title 22, Code of Federal Regulations, Parts 120-130, and/or by the U.S. Department of Commerce Bureau of Industry Security, as prescribed in the Export Administration Regulations (EAR), Title 15, Code of Federal Regulations, Parts 730-780. For further information contact the Directorate of Defense Trade Controls and/or the Bureau of Industry Security.

Multiple color palettes
Intuitive 3-summary controls
Reticle for digital zoom
4 hours runtime at 68°F on 2 CR123A batteries
Simple alignment for digital zoom capabilities
Quick detach mount
Video recording and image capture
Uploads video and images via USB-C
Battery status indicator
Ultem plastic body

UPC: 810081911689

In the Box

Armasight Jockey 320 Compact Thermal Clip-On (60Hz)
Quick Detach Mount
USB-C Cable
Light Suppressor
Thermal Zeroing Target
2 x CR123A Battery
USB Cable
Lens Cloth
Soft Case
Limited 3-Year Manufacturer Warranty (with Registration)

Additional Resources

No additional resources available

Armasight Jockey 320Specs

Key Specs

Sensor Size	320 x 240
Display	1024 x 768 OLED
Magnification	Optical: 1x Digital: 1 to 4x
Inputs/Outputs	1x USB-C
Battery	2x CR123A

General

Sensor Size	320 x 240
Display	1024 x 768 OLED
Refresh Rate	60 Hz
Pixel Size	12 µm
Thermal Sensitivity	<40 mK
Detection Range	774.6 yd / 708 m
Built-In Mic	No

Performance

Magnification	Optical: 1x Digital: 1 to 4x
Lens System	19 mm, f/1.0
Angle of View	11.58 x 8.69°

Connectivity

Inputs/Outputs	1x USB-C
GPS	No

Physical

Mounting	Yes
Battery	2x CR123A
Operating Conditions	-40 to 122°F / -40 to 50°C
Environmental Resistance	Dust/Water-Resistant (IP67)
Dimensions	6.8 x 2.7 x 2.4″ / 17.3 x 6.9 x 6.1 cm
Weight	12.8 oz / 362 g
