AG Neovo SC-27E Overview
Monitor the feed from your surveillance cameras with the SC Series 27″ 1080p LED-Backlit LCD Surveillance Monitor from AG Neovo. This unit displays video at a maximum resolution of 1920 x 1080. It features 178/178° H/V viewing angles and a 16:9 aspect ratio. This monitor is equipped with an audio input and output, built-in speakers, and a BNC output, in addition to HDMI, VGA, and BNC video inputs. VESA mount compliance offers flexible installation options.
In the Box
- AG Neovo SC Series 27″ 1080p LED-Backlit LCD Surveillance Monitor
- Power Cord
- VGA Cable
- Audio Cable
- Base
- Limited 3-Year Warranty
AG Neovo SC-27E Specs
| Screen Size (Diagonal) | 27″ |
| Resolution | 1920 x 1080 |
| Supported Display Resolutions | Maximum: 1920 x 1080 |
| Panel Type | TFT LCD |
| Brightness | 300 cd/m² |
| Viewing Angle (H x V) | 178 x 178° |
| Aspect Ratio | 16:9 |
| Dynamic Contrast Ratio | 20,000,000:1 |
| Response Time | 5 ms |
| Horizontal Frequency | 24 to 83 kHz |
| Vertical Frequency | 50 to 75 Hz |
| Backlighting Technology | LED |
| Primary Connectivity Location | Display |
| Input Ports | 1 x HDMI 1.4 Video 1 x 15-Pin VGA Video 1 x BNC Composite Video 1 x 1/8″ / 3.5 mm Audio |
| Output Ports | 1 x BNC Composite â�� Video 1 x 1/8″ / 3.5 mm â�� Audio |
| USB Ports | 1 x USB 2.0 – Service |
| Digital Media Slot | None |
| Surface Treatment | Anti-Glare |
| Hardness Rating | 3H |
| Built-In Speakers | Yes, 2 x 2 W |
| Speaker Configuration | 2-Channel |
| Tilt Adjustment | -5 to 23° |
| Power Consumption | Operational: 23.0 W Standby: < 0.5 W |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type | External |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 10 to 90% |
| Storage Humidity | 5 to 90% |
| Certifications | CE, EAC, FCC, REACH, RoHS, WEEE, as per Manufacturer |
| Wall Mounting | 100 x 100 mm |
| Lock Slot | Yes, Kensington |
| Dimensions | 24.1 x 14.4 x 2.0″ / 611.9 x 366.6 x 51.9 mm (without Stand) 24.1 x 17.9 x 9.4″ / 611.9 x 454.7 x 238.7 mm (with Stand) |
| Weight | 10.1 lb / 4.6 kg (without Stand) 11.7 lb / 5.3 kg (with Stand) |
